505433 Series

1.25mm Pitch, Micro-Lock Plus PCB Header, Dual Row, Vertical, Surface Mount, 0.38µm Gold Plating, Positive Lock, 42 Circuits, Black

Manufacturer: Molex

Catalog

1.25mm Pitch, Micro-Lock Plus PCB Header, Dual Row, Vertical, Surface Mount, 0.38µm Gold Plating, Positive Lock, 42 Circuits, Black

Part	Contact Finish - Post	Contact Shape	Contact Type	Mated Stacking Heights	Fastening Type	Style	Material Flammability Rating	Pitch - Mating	Pitch - Mating	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Number of Positions	Termination	Number of Positions Loaded	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Applications	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Current Rating (Amps)	Number of Rows	Shrouding	Voltage Rating	Insulation Color	Contact Material	Insulation Material	Connector Type	Insulation Height	Insulation Height	Features	Contact Finish - Mating
Molex 5054331071	Tin	Square	Male Pin	8.6 mm	Latch Holder	Board to Cable/Wire	UL94 V-0	1.25 mm	0.049 in	1 çm	39.4 çin	10	Solder	All	-40 °C	105 ░C	Surface Mount	Automotive General Purpose Industrial	1 µm	39.4 µin	Varies by Wire Gauge	2	Shrouded - 4 Wall	50 VAC	Black	Brass	Nylon Polyamide (PA)	Header	0.285 in	7.25 mm	Solder Retention
Molex 5054334081	Tin	Square	Male Pin	8.6 mm	Latch Holder	Board to Cable/Wire	UL94 V-0	1.25 mm	0.049 in	1 çm	39.4 çin	40	Solder	All	-40 °C	105 ░C	Surface Mount	Automotive General Purpose Industrial	1 µm	39.4 µin	Varies by Wire Gauge	2	Shrouded - 4 Wall	50 VAC	Black	Brass	Nylon Polyamide (PA)	Header	0.285 in	7.25 mm	Pick and Place Solder Retention
Molex 5054332670	Tin	Rectangular	Male Pin		Push-Pull	Board to Cable/Wire	UL94 V-0	1.25 mm	0.049 in	1 çm	39.4 çin	26	Solder	All			Surface Mount		1 µm	39.4 µin		2	Shrouded - 4 Wall		Natural	Brass	Nylon Polyamide (PA)	Header	0.285 in	7.25 mm
Molex 5054331471	Tin	Square	Male Pin	8.6 mm	Latch Holder	Board to Cable/Wire	UL94 V-0	1.25 mm	0.049 in	1 çm	39.4 çin	14	Solder	All	-40 °C	105 ░C	Surface Mount	Automotive General Purpose Industrial	1 µm	39.4 µin	Varies by Wire Gauge	2	Shrouded - 4 Wall	50 VAC	Black	Brass	Nylon Polyamide (PA)	Header	0.285 in	7.25 mm	Solder Retention
Molex 5054332071	Tin	Square	Male Pin	8.6 mm	Latch Holder	Board to Cable/Wire	UL94 V-0	1.25 mm	0.049 in	1 çm	39.4 çin	20	Solder	All	-40 °C	105 ░C	Surface Mount	Automotive General Purpose Industrial	1 µm	39.4 µin	Varies by Wire Gauge	2	Shrouded - 4 Wall	50 VAC	Black	Brass	Nylon Polyamide (PA)	Header	0.285 in	7.25 mm	Solder Retention
Molex 5054333041
Molex 5054332270	Tin-Bismuth	Rectangular	Male Pin		Push-Pull	Board to Cable/Wire	UL94 V-0	1.25 mm	0.049 in	1 çm	39.4 çin	22 positions	Solder	All	-40 °C	105 ░C	Surface Mount		1 µm	39.4 µin	Varies by Wire Gauge	2	Shrouded - 4 Wall	50 VAC	Natural	Brass	Nylon Polyamide (PA)	Header	0.285 in	7.25 mm	Solder Retention	Tin-Bismuth
Molex 5054332671	Tin	Square	Male Pin	8.6 mm	Latch Holder	Board to Cable/Wire	UL94 V-0	1.25 mm	0.049 in	1 çm	39.4 çin	26	Solder	All	-40 °C	105 ░C	Surface Mount	Automotive General Purpose Industrial	1 µm	39.4 µin	Varies by Wire Gauge	2	Shrouded - 4 Wall	50 VAC	Black	Brass	Nylon Polyamide (PA)	Header	0.285 in	7.25 mm	Solder Retention
Molex 5054332631	Gold	Square	Male Pin		Latch Holder	Board to Cable/Wire	UL94 V-0	1.25 mm	0.049 in	0.38 µm	15 µin	26	Solder	All	-40 °C	105 ░C	Surface Mount		0.38 µm	15 µin	Varies by Wire Gauge	2	Shrouded - 4 Wall	50 VAC	Black	Brass	Nylon Polyamide (PA)	Header	0.285 in	7.25 mm	Pick and Place Solder Retention	Gold
Molex 5054331871	Tin	Square	Male Pin	8.6 mm	Latch Holder	Board to Cable/Wire	UL94 V-0	1.25 mm	0.049 in	1 çm	39.4 çin	18	Solder	All	-40 °C	105 ░C	Surface Mount	Automotive General Purpose Industrial	1 µm	39.4 µin	Varies by Wire Gauge	2	Shrouded - 4 Wall	50 VAC	Black	Brass	Nylon Polyamide (PA)	Header	0.285 in	7.25 mm	Solder Retention
