629-5W1 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN D-SUB PLUG 5POS R/A SLDR
| Part | Dielectric Material | Contact Material | Color | Operating Temperature [Min] | Operating Temperature [Max] | Voltage Rating | Backset Spacing | Backset Spacing | Number of Positions | Contact Finish | Flange Feature | Features | Number of Rows [custom] | Mounting Type | Contact Finish Thickness | Shell Material, Finish | Shell Size, Connector Layout | Shell Size, Connector Layout | Connector Type | Termination | Material Flammability Rating | Contact Type | Current Rating (Amps) | Connector Style | Current Rating (Amps) | Contact Finish Thickness | Contact Finish Thickness | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | Black | -55 C | 125 °C | 125 VDC | 9.4 mm | 0.37 in | 5 | Gold | 4-40 | Board Lock Grounding Indents Mounting Brackets | 2 | Right Angle Through Hole | Flash | Nickel Plated Steel | 1 | 5W1 DE E | Plug Male Pins | Solder | UL94 V-0 | Signal and Power | 10A 5A | Combo D-Sub | ||||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | Black | -55 C | 125 °C | 125 VDC | 9.4 mm | 0.37 in | 5 | Gold | Housing/Shell (M3) | Grounding Indents Mounting Brackets | 2 | Right Angle Through Hole | Flash | 1 | 5W1 DE E | Plug Male Pins | Solder | UL94 V-0 | Signal and Power | Combo D-Sub | 5 A 30 A | |||||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | Black | -55 C | 125 °C | 125 VDC | 9.4 mm | 0.37 in | 5 | Gold | Board Side (M3) | Grounding Indents | 2 | Right Angle Through Hole | 1 | 5W1 DE E | Plug Male Pins | Solder | UL94 V-0 | Coax Signal | Combo D-Sub | 30 Áin | 0.76 Ám | |||||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | Black | -55 C | 125 °C | 125 VDC | 9.4 mm | 0.37 in | 5 | Gold | Board Side (M3) | Grounding Indents | 2 | Right Angle Through Hole | Nickel Plated Steel | 1 | 5W1 DE E | Plug Male Pins | Solder | UL94 V-0 | Signal and Power | 10A 5A | Combo D-Sub | 30 Áin | 0.76 Ám | |||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | Black | -55 C | 125 °C | 125 VDC | 9.4 mm | 0.37 in | 5 | Gold | 4-40 | Board Lock Grounding Indents Mounting Brackets | 2 | Right Angle Through Hole | Flash | Nickel Plated Steel | 1 | 5W1 DE E | Plug Male Pins | Solder | UL94 V-0 | Coax Signal | Combo D-Sub | |||||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | Black | -55 C | 125 °C | 125 VDC | 9.4 mm | 0.37 in | 5 | Gold | Housing/Shell | 2 | Right Angle Through Hole | Flash | 1 | 5W1 DE E | Plug Male Pins | Solder | UL94 V-0 | Signal and Power | Combo D-Sub | 5 A 40 A | 4-40 | |||||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | Black | -55 C | 125 °C | 125 VDC | 9.4 mm | 0.37 in | 5 | Gold | Housing/Shell (M3) | Board Lock Grounding Indents Mounting Brackets | 2 | Right Angle Through Hole | 1 | 5W1 DE E | Plug Male Pins | Solder | UL94 V-0 | Signal and Power | 20A 5A | Combo D-Sub | 30 Áin | 0.76 Ám | ||||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | Black | -55 C | 125 °C | 125 VDC | 9.4 mm | 0.37 in | 5 | Gold | Housing/Shell (M3) | Grounding Indents Mounting Brackets | 2 | Right Angle Through Hole | Flash | Nickel Plated Steel | 1 | 5W1 DE E | Plug Male Pins | Solder | UL94 V-0 | Signal and Power | Combo D-Sub | 5 A 30 A | ||||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | Black | -55 C | 125 °C | 125 VDC | 9.4 mm | 0.37 in | 5 | Gold | 4-40 | Board Lock Grounding Indents | 2 | Right Angle Through Hole | Flash | Nickel Plated Steel | 1 | 5W1 DE E | Plug Male Pins | Solder | UL94 V-0 | Signal and Power | Combo D-Sub | 5 A 40 A | ||||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | Black | -55 C | 125 °C | 125 VDC | 9.4 mm | 0.37 in | 5 | Gold | Housing/Shell (Unthreaded) | Grounding Indents Shielded | 2 | Right Angle Through Hole | 1 | 5W1 DE E | Plug Male Pins | Solder | UL94 V-0 | Coax Signal | Combo D-Sub | 30 Áin | 0.76 Ám |
