EN3P10 Series
Manufacturer: Switchcraft Inc.
Beta
⌘K
CONN RCPT FMALE 10P SOLDER CUP
| Part | Voltage Rating | Material Flammability Rating | Mounting Feature | Fastening Type | Number of Positions | Contact Material | Shielding | Ingress Protection | Applications | Contact Finish - Mating | Current Rating (Amps) | Connector Type | Orientation | Insert Material | Operating Temperature [Max] | Operating Temperature [Min] | Color | Primary Material | Termination | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Switchcraft Inc. | 250 VAC | UL94 V-0 | Bulkhead - Front Side Nut | Bayonet Lock | 10 | Copper Alloy | Unshielded | IP66/IP68 | General Purpose Instrumentation Marine Medical | Gold | 3 A | Receptacle Female Sockets | Keyed | Elastomer | 65 °C | -40 °C | Black | Plastic | ||
Switchcraft Inc. | 250 VAC | UL94 V-0 | Bulkhead - Front Side Nut | Bayonet Lock | 10 | Copper Alloy | Unshielded | IP66/IP68 | General Purpose Instrumentation Marine Medical | Gold | 3 A | Male Pins Receptacle | Keyed | Elastomer | 65 °C | -40 °C | Black | Plastic | ||
 Switchcraft Inc. | 250 VAC | UL94 V-0 | Bulkhead - Front Side Nut | Bayonet Lock | 10 | Copper Alloy | Unshielded | IP66/IP68 | General Purpose Instrumentation Marine Medical | Gold | 2 A | Receptacle Female Sockets | Keyed | Elastomer | 65 °C | -40 °C | Black | Plastic | Circuit Board Solder | Panel Mount Right Angle Through Hole |
 Switchcraft Inc. | 250 VAC | UL94 V-0 | Bulkhead - Front Side Nut | Bayonet Lock | 10 | Copper Alloy | Unshielded | IP66/IP68 | General Purpose Instrumentation Marine Medical | Gold | 2 A | Male Pins Receptacle | Keyed | Elastomer | 65 °C | -40 °C | Black | Plastic | Circuit Board Solder | Panel Mount Right Angle Through Hole |
 Switchcraft Inc. | 250 VAC | UL94 V-0 | Bulkhead - Front Side Nut | Bayonet Lock | 10 | Copper Alloy | Unshielded | IP66/IP68 | General Purpose Instrumentation Marine Medical | Gold | 3 A | Receptacle Female Sockets | Keyed | Elastomer | 65 °C | -40 °C | Black | Plastic | ||
Switchcraft Inc. | 250 VAC | UL94 V-0 | Bulkhead - Front Side Nut | Bayonet Lock | 10 | Copper Alloy | Unshielded | IP66/IP68 | General Purpose Instrumentation Marine Medical | Gold | 3 A | Male Pins Receptacle | Keyed | Elastomer | 65 °C | -40 °C | Black | Plastic | ||
 Switchcraft Inc. | 250 VAC | UL94 V-0 | Bulkhead - Front Side Nut | Bayonet Lock | 10 | Copper Alloy | Unshielded | IP66/IP68 | General Purpose Instrumentation Marine Medical | Gold | 2 A | Receptacle Female Sockets | Keyed | Elastomer | 65 °C | -40 °C | Black | Plastic | Circuit Board Solder | Panel Mount Right Angle Through Hole |
 Switchcraft Inc. | 250 VAC | UL94 V-0 | Bulkhead - Front Side Nut | Bayonet Lock | 10 | Copper Alloy | Unshielded | IP66/IP68 | General Purpose Instrumentation Marine Medical | Gold | 2 A | Male Pins Receptacle | Keyed | Elastomer | 65 °C | -40 °C | Black | Plastic | Circuit Board Solder | Panel Mount Right Angle Through Hole |
