PES1-S3 Series
Manufacturer: CUI Inc.
Beta
⌘K
DC DC CONVERTER 3.3V 1W
| Part | Applications | Standard Number | Voltage - Input (Max) [Max] | Features | Voltage - Output 1 | Number of Outputs | Type | Voltage - Isolation | Approval Agency | Package / Case | Operating Temperature [Max] | Operating Temperature [Min] | Efficiency | Voltage - Input (Min) [Min] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] | Current - Output (Max) [Max] | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 CUI Inc. | ITE (Commercial) | 55024 55032 | 3.63 V | SCP | 3.3 V | 1 | Isolated Module | 3000 V | EN | 8-SMD Module 5 Leads | 105 C | -40 °C | 73 % | 2.97 V | 12.7 mm | 7.3 mm | 8.3 mm | 12.7 mm | 0.33 in | 0.29 " | 303 mA | Surface Mount |
