N/MS3102 Series

Catalog

CONN RCPT MALE 17P SOLDER CUP

Part	Operating Temperature [Min]	Operating Temperature [Max]	Cable Opening	Cable Opening	Current Rating (Amps)	Connector Type	Material Flammability Rating	Mounting Type	Orientation	Shell Size - Insert [Min] [custom]	Shell Size - Insert [Max] [custom]	Color	Primary Material	Shell Material	Contact Finish - Mating	Fastening Type	Insert Material	Mounting Feature	Shell Finish	Contact Material	Voltage Rating	Shell Size - Insert [Min]	Shell Size - Insert [Max]	Number of Positions	Shell Size - Insert	Shell Size - Insert	Shell Size - Insert [Min] [custom]	Shell Size - Insert [Max] [custom]	Orientation [z]
JAE Electronics N/MS3102A20-29PW	-55 C	125 °C	32.56 mm	1.282 in	13 A	Receptacle Male Pins	UL94 V-0	Panel Mount	W	20	29	Black	Metal	Aluminum Alloy	Silver	Threaded	Synthetic Resin	Flange	Zinc	Copper Alloy	500 VAC
JAE Electronics N/MS3102A22-22P	-55 C	125 °C	35.71 mm	1.406 in	46 A	Receptacle Male Pins	UL94 V-0	Panel Mount	N (Normal)			Black	Metal	Aluminum Alloy	Silver	Threaded	Synthetic Resin	Flange	Zinc	Copper Alloy	500 VAC	22	22	4
JAE Electronics N/MS3102A28-21S	-55 C	125 °C	45.26 mm	1.782 in	13 A	Receptacle Female Sockets	UL94 V-0	Panel Mount	N (Normal)			Black	Metal	Aluminum Alloy	Silver	Threaded	Synthetic Resin	Flange	Zinc	Copper Alloy	500 VAC			37	21 28
JAE Electronics N/MS3102A20-29P-A528
JAE Electronics N/MS3102A14S-5S	-55 C	125 °C	23.01 mm	0.906 in	13 A	Receptacle Female Sockets	UL94 V-0	Panel Mount	N (Normal)			Black	Metal	Aluminum Alloy	Silver	Threaded	Synthetic Resin	Flange	Zinc	Copper Alloy	200 VAC			5		14S-5
JAE Electronics N/MS3102A36-10S	-55 C	125 °C	57.96 mm	2.282 in	13 A	Receptacle Female Sockets	UL94 V-0	Panel Mount	N (Normal)			Black	Metal	Aluminum Alloy	Silver	Threaded	Synthetic Resin	Flange	Zinc	Copper Alloy	500 VAC			48		36-10
JAE Electronics N/MS3102A18-10P	-55 C	125 °C	29.36 mm	1.156 in	23 A	Receptacle Male Pins	UL94 V-0	Panel Mount	N (Normal)			Black	Metal	Aluminum Alloy	Silver	Threaded	Synthetic Resin	Flange	Zinc	Copper Alloy	500 VAC			4			18	10
JAE Electronics N/MS3102A18-1S	-55 C	125 °C	29.36 mm	1.156 in	13 A	Receptacle Female Sockets	UL94 V-0	Panel Mount	N (Normal)			Black	Metal	Aluminum Alloy	Silver	Threaded	Synthetic Resin	Flange	Zinc	Copper Alloy				10		18-1
JAE Electronics N/MS3102A28-21SZ	-55 C	125 °C	45.26 mm	1.782 in	13 A	Receptacle Female Sockets	UL94 V-0	Panel Mount				Black	Metal	Aluminum Alloy	Silver	Threaded	Synthetic Resin	Flange	Zinc	Copper Alloy	500 VAC			37	21 28				Z
JAE Electronics N/MS3102A24-10P	-55 C	125 °C	38.91 mm	1.532 in	46 A	Receptacle Male Pins	UL94 V-0	Panel Mount	N (Normal)			Black	Metal	Aluminum Alloy	Silver	Threaded	Synthetic Resin	Flange	Zinc	Copper Alloy	500 VAC	24	10	7
