HEAVY DUTY POWER CONNECTORS H16B-TSH-2PG21
| Part | Operating Temperature [Max] | Operating Temperature [Min] | Housing Material | Lock Location | Housing Finish | Connector Type | Housing Color | Style | Ingress Protection | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Size | Thread Size | Features | Size / Dimension [z] | Size / Dimension [y] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | 125 °C | -40 C | Aluminum Alloy Die Cast | Locking Clip (2) on Base Bottom | Powder Coated | Hood | Gray | Side Entry Dual | IP65 - Dust Tight Water Resistant | 3.681 in | 43 mm | 2.992 in | 76 mm | 1.693 " | 93.5 mm | H16B | PG21 | |||
 TE Connectivity AMP Connectors | 125 °C | -40 C | Aluminum Alloy Die Cast | Locking Clip (1) on Base Bottom | Powder Coated | Hood | Gray | Side Entry | IP65 - Dust Tight Water Resistant | 3.118 in | 29.7 mm | 2.843 in | 72.2 mm | 1.169 in | 79.2 mm | H16A | M25 | |||
 TE Connectivity AMP Connectors | 125 °C | -40 C | Aluminum Alloy Die Cast | Locking Clip (1) on Base Bottom | Powder Coated | Hood | Gray | Top Entry | IP65 - Dust Tight Water Resistant | 3.118 in | 29.7 mm | 2.291 in | 58.2 mm | 1.169 in | 79.2 mm | H16A | M20 | |||
 TE Connectivity AMP Connectors | 125 °C | -40 C | Aluminum Alloy Die Cast | Locking Clip (2) on Base Bottom | Powder Coated | Hood | Gray | Side and Top Entry | IP65 - Dust Tight Water Resistant | 4.724 in | 43 mm | 2.992 in | 76 mm | 1.693 " | 120 mm | H24B | M32 | |||
 TE Connectivity AMP Connectors | 125 °C | -40 C | Aluminum Alloy Die Cast | Locking Clip (2) on Hood Top | Powder Coated | Hood - Coupling | Gray | Bottom Entry Top or Bottom Entry | IP65 - Dust Tight Water Resistant | 4.795 in | 44 mm | 2.461 " | 62.5 mm | 1.732 in | 121.8 mm | H24B | M25 | Cable to Cable | ||
 TE Connectivity AMP Connectors | 125 °C | -40 C | Aluminum Alloy Die Cast | Locking Clip (2) on Hood | Powder Coated | Hood | Gray | Top Entry | IP65 - Dust Tight Water Resistant | 3.681 in | 43 mm | 2.992 in | 76 mm | 1.693 " | 93.5 mm | H16B | M25 | |||
 TE Connectivity AMP Connectors | 125 °C | -40 C | Aluminum Alloy Die Cast | Locking Clip (1) on Base Bottom | Powder Coated | Hood | Gray | Side Entry | IP65 - Dust Tight Water Resistant | 2.488 in | 29.7 mm | 2.291 in | 58.2 mm | 1.169 in | 63.2 mm | H10A | M20 | |||
 TE Connectivity AMP Connectors | 125 °C | -40 C | Aluminum Alloy Die Cast | Locking Clip (1) on Base Bottom | Powder Coated | Base - Box Mount | Gray | Side Entry | IP65 - Dust Tight Water Resistant | 5.327 in | 120.4 mm | 3.921 in | 99.6 mm | 4.74 in | 135.3 mm | H48B | PG29 | Cover | ||
 TE Connectivity AMP Connectors | 125 °C | -40 C | Aluminum Alloy Die Cast | Locking Clip (1) on Base Bottom | Powder Coated | Hood | Gray | Side Entry | IP65 - Dust Tight Water Resistant | 2.362 in | 2.362 in | 1.693 " | 60 mm | H6B | PG21 | 60 mm | 43 mm | |||
 TE Connectivity AMP Connectors | 125 °C | -40 C | Aluminum Alloy Die Cast | Locking Clip (2) on Base Bottom | Powder Coated | Hood | Gray | Top Entry | IP65 - Dust Tight Water Resistant | 4.724 in | 43 mm | 2.362 in | 60 mm | 1.693 " | 120 mm | H24B |
