HR710 Series
Manufacturer: Kacon
Beta
⌘K
RELAY GEN PURPOSE 4PDT 10A 12V
| Part | Operating Temperature (Min) | Operating Temperature (Max) | Relay Type | Termination Style | Features | Coil Voltage | Operate Time | Coil Current | Switching Voltage DC (Max) | Switching Voltage AC (Max) | Mounting Type | Release Time | Contact Rating (Current) | Contact Material | Pin Count | Contact Form |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Kacon | -25 °C | 55 °C | General Purpose | Plug In | Lighted Indicator | 12 VAC | 25 ms | 125 mA | 125 VDC | 250 VAC | Socketable | 25 ms | 10 A | Gold (Au) Silver (Ag) | 4 | 4 C Form PDT |
 Kacon | -25 °C | 55 °C | General Purpose | Plug In | Lighted Indicator | 12 VAC | 25 ms | 0.075 A | 125 VDC | 250 VAC | Socketable | 25 ms | 10 A | Gold (Au) Silver (Ag) | 2 2 Form C C DPDT Form | |
Kacon | -25 °C | 55 °C | General Purpose | Plug In | Lighted Indicator | 220 V | 25 ms | 11.4 mA | 125 VDC | 250 VAC | Socketable | 25 ms | 10 A | Gold (Au) Silver (Ag) | 4 | 4 C Form PDT |
Kacon | -25 °C | 55 °C | General Purpose | Plug In | Lighted Indicator Surge Protection | 220 V | 25 ms | 5.5 mA | 125 VDC | 250 VAC | Socketable | 25 ms | 10 A | Gold (Au) Silver (Ag) | 2 2 Form C C DPDT Form | |
Kacon | -25 °C | 55 °C | General Purpose | Plug In | Diode Lighted Indicator | 12 VAC | 25 ms | 0.075 A | 125 VDC | 250 VAC | Socketable | 25 ms | 10 A | Gold (Au) Silver (Ag) | 2 2 Form C C DPDT Form | |
Kacon | -25 °C | 55 °C | General Purpose | Plug In | Lighted Indicator | 24 VDC | 25 ms | 104 mA | 125 VDC | 250 VAC | Socketable | 25 ms | 10 A | Gold (Au) Silver (Ag) | 4 | 4 C Form PDT |
Kacon | -25 °C | 55 °C | General Purpose | Plug In | Lighted Indicator | 110 V | 25 ms | 10.9 mA | 125 VDC | 250 VAC | Socketable | 25 ms | 10 A | Gold (Au) Silver (Ag) | 2 2 Form C C DPDT Form | |
Kacon | -25 °C | 55 °C | General Purpose | Plug In | Diode Lighted Indicator | 24 VDC | 25 ms | 0.0375 A | 125 VDC | 250 VAC | Socketable | 25 ms | 10 A | Gold (Au) Silver (Ag) | 2 2 Form C C DPDT Form | |
Kacon | -25 °C | 55 °C | General Purpose | Plug In | Lighted Indicator | 24 VDC | 25 ms | 50 mA | 125 VDC | 250 VAC | Socketable | 25 ms | 10 A | Gold (Au) Silver (Ag) | 2 2 Form C C DPDT Form | |
Kacon | -25 °C | 55 °C | General Purpose | Plug In | Lighted Indicator | 220 V | 25 ms | 5.5 mA | 125 VDC | 250 VAC | Socketable | 25 ms | 10 A | Gold (Au) Silver (Ag) | 2 2 Form C C DPDT Form |
