174821 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
CONN HEADER SMD 20POS 1.25MM
| Part | Insulation Color | Material Flammability Rating | Number of Positions Loaded | Shrouding | Number of Positions | Contact Shape | Row Spacing - Mating | Row Spacing - Mating | Number of Rows [custom] | Voltage Rating | Contact Finish - Post | Pitch - Mating | Pitch - Mating | Fastening Type | Features | Insulation Height | Insulation Height | Operating Temperature [Min] | Operating Temperature [Max] | Connector Type | Contact Material | Current Rating (Amps) | Insulation Material | Mounting Type | Contact Type | Termination | Insulation Height [z] | Insulation Height [z] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | Black | UL94 V-0 | All | Shrouded - 4 Wall | 20 | Circular | 1.25 mm | 0.049 in | 2 | 50 V | Tin | 0.049 in | 1.25 mm | Push-Pull | Board Guide | 0.215 in | 5.45 mm | -30 ░C | 105 ░C | Header | Brass | 0.5 A | Polyphenylene Sulfide (PPS) | Surface Mount | Male Pin | Solder | ||
TE Connectivity AMP Connectors | Black | UL94 V-0 | All | Shrouded - 4 Wall | 12 | Circular | 1.25 mm | 0.049 in | 2 | 50 V | Tin | 0.049 in | 1.25 mm | Push-Pull | Board Guide | -30 ░C | 105 ░C | Header | Brass | 0.5 A | Polyphenylene Sulfide (PPS) | Surface Mount | Male Pin | Solder | 5.95 mm | 0.234 in | ||
 TE Connectivity AMP Connectors | Black | UL94 V-0 | All | Shrouded - 4 Wall | 10 | Circular | 1.25 mm | 0.049 in | 2 | 50 V | Tin | 0.049 in | 1.25 mm | Push-Pull | Board Guide | 0.156 in | 3.96 mm | -30 ░C | 105 ░C | Header | Brass | 0.5 A | Polyphenylene Sulfide (PPS) | Surface Mount | Male Pin | Solder | ||
TE Connectivity AMP Connectors | Black | UL94 V-0 | All | Shrouded - 4 Wall | 6 | Circular | 1.25 mm | 0.049 in | 2 | 50 V | Tin | 0.049 in | 1.25 mm | Push-Pull | Board Guide | 0.156 in | 3.96 mm | -30 ░C | 105 ░C | Header | Brass | 0.5 A | Polyphenylene Sulfide (PPS) | Surface Mount | Male Pin | Solder | ||
TE Connectivity AMP Connectors | Black | UL94 V-0 | All | Shrouded - 4 Wall | 20 | Circular | 1.25 mm | 0.049 in | 2 | 50 V | Tin | 0.049 in | 1.25 mm | Push-Pull | Board Guide | 0.156 in | 3.96 mm | -30 ░C | 105 ░C | Header | Brass | 0.5 A | Polyphenylene Sulfide (PPS) | Surface Mount | Male Pin | Solder | ||
TE Connectivity AMP Connectors | Black | UL94 V-0 | All | Shrouded - 4 Wall | 22 | Circular | 1.25 mm | 0.049 in | 2 | 50 V | Tin | 0.049 in | 1.25 mm | Push-Pull | Board Guide | 0.156 in | 3.96 mm | -30 ░C | 105 ░C | Header | Brass | 0.5 A | Polyphenylene Sulfide (PPS) | Surface Mount | Male Pin | Solder |
