Micro-Fit+ Right-Angle Header, Through Hole, 3.00mm Pitch, Single Row, 2 Circuits, Matte Tin (Sn) Plating, Glow-Wire Capable, Black
Micro-Fit+ Right-Angle Header, Through Hole, 3.00mm Pitch, Single Row, 2 Circuits, Matte Tin (Sn) Plating, Glow-Wire Capable, Black
Micro-Fit+ Right-Angle Header, Through Hole, 3.00mm Pitch, Single Row, 2 Circuits, Matte Tin (Sn) Plating, Glow-Wire Capable, Black
| Part | Style | Number of Positions Loaded | Number of Positions | Fastening Type | Pitch - Mating | Pitch - Mating | Voltage Rating | Contact Finish - Mating | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Current Rating (Amps) | Contact Finish - Post | Connector Type | Shrouding | Contact Shape | Contact Length - Post [x] | Contact Length - Post [x] | Features | Termination | Insulation Height | Insulation Height | Mounting Type | Number of Rows | Contact Material | Material Flammability Rating | Insulation Color | Operating Temperature [Min] | Operating Temperature [Max] | Contact Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | Board to Cable/Wire | All | 4 | Locking Ramp | 0.118 in | 3 mm | 600 VAC | Gold | 15 µin | 0.38 µm | Varies by Wire Gauge | Tin | Header | Shrouded - 4 Wall | Square | 3.18 mm | 0.125 in | Board Lock Glow Wire Compliant | Solder | 0.173 in | 4.4 mm | Through Hole Right Angle | 1 | Copper Alloy | UL94 V-0 | Black | -40 °C | 105 ░C | Male Pin |
 Molex | Board to Cable/Wire | All | 8 | Locking Ramp | 0.118 in | 3 mm | 600 VAC | Gold | 3 µin | 0.076 µm | Varies by Wire Gauge | Tin | Header | Shrouded - 4 Wall | Square | 3.18 mm | 0.125 in | Board Lock Glow Wire Compliant | Solder | 0.173 in | 4.4 mm | Through Hole Right Angle | 1 | Copper Alloy | UL94 V-0 | Black | -40 °C | 105 ░C | Male Pin |
 Molex | Board to Cable/Wire | All | Locking Ramp | 0.118 in | 3 mm | 600 VAC | Varies by Wire Gauge | Tin | Header | Shrouded - 4 Wall | Square | 3.18 mm | 0.125 in | Board Guide Pick and Place | Solder | 0.231 in | 5.87 mm | Through Hole Right Angle | 1 | Copper Alloy | UL94 V-0 | Yellow | -40 °C | 105 ░C | Male Pin | ||||
 Molex | Board to Cable/Wire | All | Locking Ramp | 0.118 in | 3 mm | 600 VAC | Gold | 30 Áin | 0.76 Ám | Varies by Wire Gauge | Tin | Header | Shrouded - 4 Wall | Square | 3.18 mm | 0.125 in | Board Lock Glow Wire Compliant | Solder | 0.23 in | 5.85 mm | Through Hole Right Angle | 1 | Copper Alloy | UL94 V-0 | Blue | -40 °C | 105 ░C | Male Pin | |
 Molex | Board to Cable/Wire | All | 2 | Locking Ramp | 0.118 in | 3 mm | 600 VAC | Varies by Wire Gauge | Tin | Header | Shrouded - 4 Wall | Square | 3.18 mm | 0.125 in | Board Guide Pick and Place | Solder | 0.231 in | 5.87 mm | Through Hole Right Angle | 1 | Copper Alloy | UL94 V-0 | Yellow | -40 °C | 105 ░C | Male Pin | |||
 Molex | Board to Cable/Wire | All | 7 | Locking Ramp | 0.118 in | 3 mm | 600 VAC | Gold | 15 µin | 0.38 µm | Varies by Wire Gauge | Tin | Header | Shrouded - 4 Wall | Square | 3.18 mm | 0.125 in | Board Lock Glow Wire Compliant | Solder | 0.173 in | 4.4 mm | Through Hole Right Angle | 1 | Copper Alloy | UL94 V-0 | Black | -40 °C | 105 ░C | Male Pin |
 Molex | Board to Cable/Wire | All | 2 | Locking Ramp | 0.118 in | 3 mm | 600 VAC | Gold | 15 µin | 0.38 µm | Varies by Wire Gauge | Tin | Header | Shrouded - 4 Wall | Square | 3.18 mm | 0.125 in | Board Lock Glow Wire Compliant | Solder | 0.173 in | 4.4 mm | Through Hole Right Angle | 1 | Copper Alloy | UL94 V-0 | Black | -40 °C | 105 ░C | Male Pin |
Molex | Board to Cable/Wire | All | Locking Ramp | 0.118 in | 3 mm | 600 VAC | Gold | 15 µin | 0.38 µm | Varies by Wire Gauge | Tin | Header | Shrouded - 4 Wall | Square | 3.18 mm | 0.125 in | Board Lock Glow Wire Compliant | Solder | 0.173 in | 4.4 mm | Through Hole Right Angle | 1 | Copper Alloy | UL94 V-0 | Black | -40 °C | 105 ░C | Male Pin | |
Molex | Board to Cable/Wire | All | 4 | Locking Ramp | 0.118 in | 3 mm | 600 VAC | Varies by Wire Gauge | Tin | Header | Shrouded - 4 Wall | Square | 3.18 mm | 0.125 in | Board Guide Pick and Place | Solder | 0.231 in | 5.87 mm | Through Hole Right Angle | 1 | Copper Alloy | UL94 V-0 | Yellow | -40 °C | 105 ░C | Male Pin | |||
Molex | Board to Cable/Wire | All | Locking Ramp | 0.118 in | 3 mm | 600 VAC | Gold | 15 µin | 0.38 µm | Varies by Wire Gauge | Tin | Header | Shrouded - 4 Wall | Square | 3.18 mm | 0.125 in | Board Lock Glow Wire Compliant | Solder | 0.173 in | 4.4 mm | Through Hole Right Angle | 1 | Copper Alloy | UL94 V-0 | Black | -40 °C | 105 ░C | Male Pin |
