9GP5724 Series
Manufacturer: Sanyo Denki America Inc.
Beta
⌘K
FAN AXIAL 172X51MM 24VDC WIRE
| Part | Voltage Range [Max] | Voltage Range [Min] | Current Rating (Amps) | Material - Frame | Material - Blade | Lifetime @ Temp. | Voltage - Rated | Bearing Type | Width [x] | Static Pressure | Static Pressure | Weight | Weight | Features | Termination | Size / Dimension | Size / Dimension [y] | Size / Dimension [x] | Noise | Fan Type | Approval Agency | Power (Watts) | RPM | Air Flow | Air Flow | Operating Temperature [Min] | Operating Temperature [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Sanyo Denki America Inc. | 30 V | 16 VDC | 5 A | Aluminum | Plastic | Varies Based on Temperature | 24 VDC | Ball | 51 mm | 4.017 in H2O | 1000.6 Pa | 861.8 g | 1.9 lbs | PWM Control Speed Sensor (Tach) | 4 Wire Leads | Rectangular/Rounded | 150 mm | 172 mm | 77 dB | Tubeaxial | cURus TUV | 120 W | 8000 RPM | 434 CFM | 12.15 m³/min | -20 ░C | 70 °C |
