8427 Series
Manufacturer: Belden Inc.
Beta
⌘K
7 #20 EPDM BRD EPDM
| Part | Shield Coverage | Conductor Strand | Usage | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Jacket Color | Shield Material | Operating Temperature [Max] | Operating Temperature [Min] | Shield Type | Jacket (Insulation) Material | Conductor Insulation | Voltage | Length | Length | Wire Gauge | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Number of Conductors | Conductor Material | Cable Type | Length [x] | Length [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | 85 % | 26 34 AWG | Audio | 0.355 " | 9.02 mm | Black | Viscose; Copper Tinned | 90 °C | -50 °C | Double Braid | Ethylene Propylene Terpolymer Rubber (EPDM) | Ethylene Propylene Terpolymer Rubber (EPDM) | 600 V | 3000 " | 76.2 m | 20 AWG | 1.041 mm | 0.041 in | 7 | Copper Tinned | Microphone | ||
Belden Inc. | 85 % | 26 34 AWG | Audio | 0.355 " | 9.02 mm | Black | Viscose; Copper Tinned | 90 °C | -50 °C | Double Braid | Ethylene Propylene Terpolymer Rubber (EPDM) | Ethylene Propylene Terpolymer Rubber (EPDM) | 600 V | 20 AWG | 1.041 mm | 0.041 in | 7 | Copper Tinned | Microphone | 30.5 m | 100 ft |
