502430 Series

SlimStack Board-to-Board Plug, 0.40mm Pitch, Surface Mount, Dual Row, Vertical Stacking, 1.00mm Stacking Height, with Solder Tabs, with Vacuum Tape, 14 Circuits

Manufacturer: Molex

Catalog

SlimStack Board-to-Board Plug, 0.40mm Pitch, Surface Mount, Dual Row, Vertical Stacking, 1.00mm Stacking Height, with Solder Tabs, with Vacuum Tape, 14 Circuits

Part	Height Above Board [z]	Height Above Board [z]	Mated Stacking Heights	Pitch [x]	Pitch [x]	Contact Finish Thickness	Contact Finish Thickness	Number of Rows	Contact Finish	Connector Type	Mounting Type	Number of Positions	Features
Molex 5024308010	0.8 mm	0.031 in	1 mm	0.016 in	0.4 mm	4 Áin	0.1 Ám	2	Gold	Outer Shroud Contacts Plug	Surface Mount	80	Solder Retention
Molex 5024302010	0.8 mm	0.031 in	1 mm	0.016 in	0.4 mm	4 Áin	0.1 Ám	2	Gold	Outer Shroud Contacts Plug	Surface Mount	20	Solder Retention
Molex 5024301412	0.8 mm	0.031 in	1 mm	0.016 in	0.4 mm	4 Áin	0.1 Ám	2	Gold	Outer Shroud Contacts Plug	Surface Mount	14	Solder Retention
Molex 5024302230	0.8 mm	0.031 in	1 mm	0.016 in	0.4 mm	4 Áin	0.1 Ám	2	Gold	Outer Shroud Contacts Plug	Surface Mount	22 positions	Solder Retention
Molex 5024302030	0.8 mm	0.031 in	1 mm	0.016 in	0.4 mm	4 Áin	0.1 Ám	2	Gold	Outer Shroud Contacts Plug	Surface Mount	20	Solder Retention
Molex 5024303210	0.8 mm	0.031 in	1 mm	0.016 in	0.4 mm	4 Áin	0.1 Ám	2	Gold	Outer Shroud Contacts Plug	Surface Mount		Solder Retention
Molex 5024308012	0.8 mm	0.031 in	1 mm	0.016 in	0.4 mm	4 Áin	0.1 Ám	2	Gold	Outer Shroud Contacts Plug	Surface Mount	80	Solder Retention
Molex 5024302612	0.8 mm	0.031 in	1 mm	0.016 in	0.4 mm	4 Áin	0.1 Ám	2	Gold	Outer Shroud Contacts Plug	Surface Mount	26	Solder Retention
Molex 5024304012	0.8 mm	0.031 in	1 mm	0.016 in	0.4 mm	4 Áin	0.1 Ám	2	Gold	Outer Shroud Contacts Plug	Surface Mount	40	Solder Retention
Molex 5024301410	0.8 mm	0.031 in	1 mm	0.016 in	0.4 mm	4 Áin	0.1 Ám	2	Gold	Outer Shroud Contacts Plug	Surface Mount	14	Solder Retention
