470027YY Series
Manufacturer: ALPHA WIRE
Beta
⌘K
MULTICONDUCTOR CABLE, PRO-MET®, YY CONTROL, UNSHIELDED, 2 CONDUCTOR, 19 AWG, 0.75 MM², 164 FT, 50 M
| Part | Cable Type | Length | Length | Conductor Insulation | Usage | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Features | Number of Conductors | Jacket (Insulation) Material | Voltage | Wire Gauge | Conductor Material | Operating Temperature [Max] | Operating Temperature [Min] | Conductor Strand [custom] | Conductor Strand [diameter] | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Jacket Color | Spool Size | Spool Size | Length | Length [x] | Length [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ALPHA WIRE | Multi-Conductor | 50 m | 164 ft | Poly-Vinyl Chloride (PVC) | Industrial | 0.026 " | 0.66 mm | Chemical Resistant Oil Resistant UV Resistant | 2 | Poly-Vinyl Chloride (PVC) | 300 VDC | 19 AWG | Copper Bare | 80 °C | -40 C | 30 | 0.007 in | 0.206 in | 5.23 mm | Gray | |||||
ALPHA WIRE | Multi-Conductor | 1 m 10 m 20 m | 3.28 ft 32.81 ft 65.62 ft | Poly-Vinyl Chloride (PVC) | Industrial | 0.026 " | 0.66 mm | Chemical Resistant Oil Resistant UV Resistant | 2 | Poly-Vinyl Chloride (PVC) | 300 VDC | 19 AWG | Copper Bare | 80 °C | -40 C | 30 | 0.007 in | 0.206 in | 5.23 mm | Gray | 984.3 ft | 300 m | Enter Number of Meters in Order Quantity | 30 m 300 m | 98.43 ft 984.3 ft |
