629-M15 Series
Manufacturer: EDAC Inc.
Beta
⌘K
629M SERIES RIGHT ANGLE D-SUB PL
| Part | Contact Material | Operating Temperature [Min] | Operating Temperature [Max] | Dielectric Material | Color | Connector Type | Backset Spacing | Backset Spacing | Connector Style | Shell Size, Connector Layout | Current Rating (Amps) | Features | Material Flammability Rating | Termination | Contact Finish | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Contact Type | Number of Positions | Number of Rows [custom] | Flange Feature | Flange Feature | Contact Finish Thickness | Shell Material, Finish |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Copper Alloy | -55 C | 125 °C | Polyamide (PA6T) Nylon 6T | Black | Plug Male Pins | 9.4 mm | 0.37 in | Combo D-Sub | 2 | 5 A | Grounding Indents Mounting Brackets Shielded | UL94 V-0 | Solder | Gold | Right Angle Through Hole | 30 Áin | 0.76 Ám | Signal | 15 | 2 | Board Side (4-40) | |||
 EDAC Inc. | Copper Alloy | -55 C | 125 °C | Polyamide (PA6T) Nylon 6T | Black | Plug Male Pins | 9.4 mm | 0.37 in | Combo D-Sub | 2 | 5 A | Grounding Indents Shielded | UL94 V-0 | Solder | Gold | Right Angle Through Hole | 30 Áin | 0.76 Ám | Signal | 15 | 2 | Housing/Shell | 4-40 | ||
 EDAC Inc. | Copper Alloy | -55 C | 125 °C | Polyamide (PA6T) Nylon 6T | Black | Plug Male Pins | 9.4 mm | 0.37 in | Combo D-Sub | 2 | 5 A | Grounding Indents Mounting Brackets Shielded | UL94 V-0 | Solder | Gold | Right Angle Through Hole | Signal | 15 | 2 | 4-40 | Flash | ||||
 EDAC Inc. | Copper Alloy | -55 C | 125 °C | Polyamide (PA6T) Nylon 6T | Black | Plug Male Pins | 9.4 mm | 0.37 in | Combo D-Sub | 2 | 5 A | Grounding Indents Shielded | UL94 V-0 | Solder | Gold | Right Angle Through Hole | Signal | 15 | 2 | Housing/Shell | 4-40 | Flash | |||
 EDAC Inc. | Copper Alloy | -55 C | 125 °C | Polyamide (PA6T) Nylon 6T | Black | Plug Male Pins | 9.4 mm | 0.37 in | Combo D-Sub | 2 | 5 A | Grounding Indents Mounting Brackets Shielded | UL94 V-0 | Solder | Gold | Right Angle Through Hole | Signal | 15 | 2 | Board Side (4-40) | Flash | ||||
 EDAC Inc. | Copper Alloy | -55 C | 125 °C | Polyamide (PA6T) Nylon 6T | Black | Plug Male Pins | 9.4 mm | 0.37 in | Combo D-Sub | 2 | 5 A | Grounding Indents Mounting Brackets Shielded | UL94 V-0 | Solder | Gold | Right Angle Through Hole | 15 µin | 0.38 µm | Signal | 15 | 2 | Board Side (4-40) | Nickel Plated Steel | ||
 EDAC Inc. | Copper Alloy | -55 C | 125 °C | Polyamide (PA6T) Nylon 6T | Black | Plug Male Pins | 9.4 mm | 0.37 in | Combo D-Sub | 2 | 5 A | Grounding Indents Shielded | UL94 V-0 | Solder | Gold | Right Angle Through Hole | 15 µin | 0.38 µm | Signal | 15 | 2 | Housing/Shell | 4-40 | Nickel Plated Steel | |
 EDAC Inc. | Copper Alloy | -55 C | 125 °C | Polyamide (PA6T) Nylon 6T | Black | Plug Male Pins | 9.4 mm | 0.37 in | Combo D-Sub | 2 | 5 A | Grounding Indents Shielded | UL94 V-0 | Solder | Gold | Right Angle Through Hole | 15 µin | 0.38 µm | Signal | 15 | 2 | Housing/Shell | 4-40 | Nickel Plated Steel | |
 EDAC Inc. | Copper Alloy | -55 C | 125 °C | Polyamide (PA6T) Nylon 6T | Black | Plug Male Pins | 9.4 mm | 0.37 in | Combo D-Sub | 2 | 5 A | Grounding Indents Mounting Brackets Shielded | UL94 V-0 | Solder | Gold | Right Angle Through Hole | 30 Áin | 0.76 Ám | Signal | 15 | 2 | Housing/Shell | 4-40 | Nickel Plated Steel | |
 EDAC Inc. | Copper Alloy | -55 C | 125 °C | Polyamide (PA6T) Nylon 6T | Black | Plug Male Pins | 9.4 mm | 0.37 in | Combo D-Sub | 2 | 5 A | Grounding Indents Mounting Brackets Shielded | UL94 V-0 | Solder | Gold | Right Angle Through Hole | 30 Áin | 0.76 Ám | Signal | 15 | 2 | Board Side (4-40) | Nickel Plated Steel |
