9LG0912 Series

Catalog

AXIAL FAN, 92MM, 12VDC, 102.4CFM, 55DBA

Part	Lifetime @ Temp.	Material - Blade	Voltage Range [Min]	Voltage Range [Max]	Current Rating (Amps)	Material - Frame	Bearing Type	Width [y]	RPM	Fan Type	Voltage - Rated	Air Flow	Air Flow	Size / Dimension [y]	Size / Dimension [x]	Features	Termination	Weight	Weight	Approval Agency	Power (Watts)	Noise	Operating Temperature [Min]	Operating Temperature [Max]	Static Pressure	Static Pressure
Sanyo Denki America Inc. 9LG0912P1F001	180000 Hrs	Plastic	10.2 VDC	13.8 VDC	1 A	Aluminum	Ball	38 mm	7000 RPM	Tubeaxial	12 VDC	2.87 m³/min	102.4 CFM	92 mm	92 mm	Locked Rotor Protection PWM Control Speed Sensor (Tach)	4 Wire Leads	0.604 lb	273.97 g	CSA TUV UL	12 W	55 dB(A)	-20 ░C	70 °C	1.05 in H2O	261.5 Pa
Sanyo Denki America Inc. 9LG0912S4001	180000 Hrs	Plastic	10.8 VDC	13.2 VDC	0.22 A	Aluminum	Ball	25 mm	3850 RPM	Tubeaxial	12 VDC	1.67 m³/min	59.7 CFM	92 mm	92 mm	Locked Rotor Protection Speed Sensor (Tach)	3 Wire Leads			CSA TUV UL	2.64 W	37 dB	-20 ░C	70 °C	0.25 in H2O	62.3 Pa
Sanyo Denki America Inc. 9LG0912H4002	180000 Hrs	Plastic	10.8 VDC	13.2 VDC	150 mA	Aluminum	Ball	25 mm	3150 RPM	Tubeaxial	12 VDC	1.36 m³/min	48.7 CFM	92 mm	92 mm		2 Wire Leads			CSA TUV UL	1.8 W	32 dB	-20 ░C	70 °C	0.17 in H2O	42.3 Pa
Sanyo Denki America Inc. 9LG0912P4H001	180000 Hrs	Plastic	10.8 VDC	13.2 VDC	150 mA	Aluminum	Ball	25 mm	3150 RPM	Tubeaxial	12 VDC	1.36 m³/min	48.7 CFM	92 mm	92 mm	PWM Control Speed Sensor (Tach)	4 Wire Leads	0.331 lb	150.14 g	CSA TUV UL	1.8 W	32 dB	-20 ░C	70 °C	0.17 in H2O	42.3 Pa
