GLBC02 Series
Manufacturer: Honeywell Sensing and Productivity Solutions
Beta
⌘K
SWITCH SNAP ACTION SPDT 6A 120V
| Part | Differential Travel | Termination Style | Voltage Rating - AC | Switch Function | Operating Position | Ingress Protection | Voltage Rating - DC | Operating Temperature [Min] | Operating Temperature [Max] | Mounting Type | Actuator Type | Operating Force | Circuit | Overtravel | Mechanical Life | Current Rating (Amps) | Pretravel |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Honeywell Sensing and Productivity Solutions | 12 ° | Plug In | 120 V | On-Mom | 26 ° | IP67 - Dust Tight Waterproof | 125 VDC | -25 °C | 85 °C | Chassis Mount | Side Rotary Adjustable Rod | 33 gfm | SPDT | 59 ° | 15000000 Cycles | 6 A 550 mA | 26 ° |
 Honeywell Sensing and Productivity Solutions | Plug In | 120 V | On-Mom | 18 ° | IP67 - Dust Tight Waterproof | 125 VDC | -25 °C | 85 °C | Chassis Mount | Coil Spring | 10 gfm | SPDT | 15000000 Cycles | 6 A 550 mA | 18 ° | ||
 Honeywell Sensing and Productivity Solutions | 12 ° | Plug In | 120 V | On-Mom | 26 ° | IP67 - Dust Tight Waterproof | 125 VDC | -25 °C | 85 °C | Chassis Mount | Roller Side Rotary | 33 gfm | SPDT | 59 ° | 15000000 Cycles | 6 A 550 mA | 26 ° |
