325 Series
Manufacturer: EDAC Inc.
Beta
⌘K
STANDARD CARD EDGE CONNECTORS CARD EDGE CONNECTOR
| Part | Material - Insulation | Termination Rows [custom] | Card Type | Contact Material | Operating Temperature [Min] | Operating Temperature [Max] | Number of Rows [custom] | Contact Finish Thickness | Contact Finish Thickness | Contact Finish | Mounting Type | Card Thickness | Card Thickness | Read Out | Pitch | Pitch | Color | Termination | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Contact Type | Number of Positions | Number of Positions/Bay/Row | Gender | Number of Rows | Termination Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Non Specified - Dual Edge | Copper Alloy | -65 ░C | 125 °C | 2 | 0.25 Ám | 10 Áin | Gold | Through Hole | 3.18 mm | 0.125 in | Dual | 0.1 " | 2.54 mm | Green | Solder Eyelet(s) | Flush Mount Top Opening Unthreaded | 0.16 " | 4.06 mm | Cantilever | 46 | 23 | Female | ||
 EDAC Inc. | Non Specified - Single Edge | Copper Alloy | -65 ░C | 125 °C | 0.25 Ám | 10 Áin | Gold | Through Hole | 3.18 mm | 0.125 in | Single | 0.1 " | 2.54 mm | Green | Solder | Flush Mount Top Opening Unthreaded | 0.16 " | 4.06 mm | Cantilever | 19 | 19 | Female | 1 | ||||
 EDAC Inc. | Non Specified - Dual Edge | Copper Alloy | -65 ░C | 125 °C | 2 | 0.25 Ám | 10 Áin | Gold | Through Hole | 3.18 mm | 0.125 in | Dual | 0.1 " | 2.54 mm | Green | Solder | Flush Mount Top Opening Unthreaded | 0.16 " | 4.06 mm | Cantilever | 104 | 52 | Female | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Non Specified - Dual Edge | Copper Alloy | -65 ░C | 125 °C | 2 | 0.25 Ám | 10 Áin | Gold | Through Hole | 3.18 mm | 0.125 in | Dual | 0.1 " | 2.54 mm | Green | Solder Eyelet(s) | Flush Mount Top Opening Unthreaded | 0.16 " | 4.06 mm | Cantilever | 72 | 36 | Female | ||
 EDAC Inc. | Non Specified - Single Edge | Copper Alloy | -65 ░C | 125 °C | 0.25 Ám | 10 Áin | Gold | Through Hole | 3.18 mm | 0.125 in | Single | 0.1 " | 2.54 mm | Green | Solder | Flush Mount Top Opening Unthreaded | 0.16 " | 4.06 mm | Cantilever | 27 | 27 | Female | 1 | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Non Specified - Dual Edge | Copper Alloy | -65 ░C | 125 °C | 2 | 0.25 Ám | 10 Áin | Gold | Through Hole | 3.18 mm | 0.125 in | Dual | 0.1 " | 2.54 mm | Green | Solder | 4-40 Flush Mount Threaded Insert Top Opening | Cantilever | 96 | 48 | Female | ||||
 EDAC Inc. | Non Specified - Dual Edge | Copper Alloy | -65 ░C | 125 °C | 2 | 0.25 Ám | 10 Áin | Gold | Through Hole | 3.18 mm | 0.125 in | Dual | 0.1 " | 2.54 mm | Green | Solder Eyelet(s) | Cantilever | 56 | 28 | Female | |||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Non Specified - Single Edge | Copper Alloy | -65 ░C | 125 °C | 0.25 Ám | 10 Áin | Gold | Through Hole | 3.18 mm | 0.125 in | Single | 0.1 " | 2.54 mm | Green | Wire Wrap | 4-40 Flush Mount Threaded Insert Top Opening | Cantilever | 30 | 15 | Female | 1 | 1 | ||||
EDAC Inc. | Diallyl Phthalate (DAP) | Non Specified - Single Edge | Copper Alloy | -65 ░C | 125 °C | 0.25 Ám | 10 Áin | Gold | Through Hole | 3.18 mm | 0.125 in | Single | 0.1 " | 2.54 mm | Green | Wire Wrap | Flush Mount Top Opening Unthreaded | 0.16 " | 4.06 mm | Cantilever | 39 | 39 | Female | 1 | 1 | ||
EDAC Inc. | Diallyl Phthalate (DAP) | Non Specified - Single Edge | Copper Alloy | -65 ░C | 125 °C | 0.25 Ám | 10 Áin | Gold | Through Hole | 3.18 mm | 0.125 in | Single | 0.1 " | 2.54 mm | Green | Solder | Flush Mount Top Opening Unthreaded | 0.16 " | 4.06 mm | Cantilever | 46 | 46 | Female | 1 | 1 |
