S9AW Series
Manufacturer: NKK Switches
Beta
⌘K
TOGGLE SWITCH, ON-OFF-(ON), SPDT, NON ILLUMINATED, 20 A, PANEL MOUNT
| Part | Actuator Material | Electrical Life | Operating Temperature [Min] | Operating Temperature [Max] | Voltage Rating - AC | Circuit | Termination Style | Voltage Rating - DC | Current Rating (Amps) | Mounting Type | Actuator Length [x] | Bushing Thread | Illumination | Switch Function | Panel Cutout Dimensions [diameter] | Ingress Protection | Actuator Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NKK Switches | Brass Chrome Plated | 25000 Steps | -30 ░C | 70 °C | 125 V | SPDT | Quick Connect - 0.250" (6.3mm) | 30 V | 15 A 20 A | Panel Mount | 17.5 mm | M12 x 1 | Non-Illuminated | On-Off-Mom | 12.5 mm | IP67 - Dust Tight Waterproof | Standard Round |
