307-058 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 58POS 0.156
| Part | Material - Insulation | Termination Rows [custom] | Number of Rows [custom] | Termination | Number of Positions | Contact Type | Mounting Type | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material | Number of Positions/Bay/Row | Color | Features | Read Out | Pitch | Pitch | Card Type | Card Thickness [Max] | Card Thickness [Min] | Contact Finish | Gender | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Contact Finish Thickness | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 2 | 2 | Solder Eyelet(s) | 58 | Semi Bellows | Board Edge Straddle Mount | -40 C | 105 ░C | Copper Alloy | 29 | Green | Card Extender | Dual | 3.96 mm | 0.156 in | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Tin | Female | |||||
 EDAC Inc. | Polyester Thermoplastic | 2 | 2 | Solder | 58 | Semi Bellows | Right Angle Through Hole | -40 C | 105 ░C | Copper Alloy | 29 | Green | Dual | 3.96 mm | 0.156 in | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Tin | Female | 4-40 Flush Mount Threaded Insert Top Opening | |||||
 EDAC Inc. | Polyester Thermoplastic | 2 | 2 | Solder Eyelet(s) | 58 | Semi Bellows | Through Hole | -40 C | 105 ░C | Copper Alloy | 29 | Green | Dual | 3.96 mm | 0.156 in | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Female | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 0.25 Ám | 10 Áin | |
 EDAC Inc. | Polyester Thermoplastic | 2 | 2 | Solder | 58 | Semi Bellows | Board Edge Straddle Mount | -40 C | 105 ░C | Copper Alloy | 29 | Green | Dual | 3.96 mm | 0.156 in | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Tin | Female | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | |||
 EDAC Inc. | Polyester Thermoplastic | 2 | 2 | Solder | 58 | Semi Bellows | Right Angle Through Hole | -40 C | 105 ░C | Copper Alloy | 29 | Green | Card Guides | Dual | 3.96 mm | 0.156 in | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Tin | Female | 4-40 Flush Mount Threaded Insert Top Opening | ||||
 EDAC Inc. | Polyester Thermoplastic | 2 | 2 | Solder | 58 | Semi Bellows | Right Angle Through Hole | -40 C | 105 ░C | Copper Alloy | 29 | Green | Dual | 3.96 mm | 0.156 in | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Tin | Female | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | |||
 EDAC Inc. | Polyester Thermoplastic | 2 | 2 | Solder | 58 | Semi Bellows | Through Hole | -40 C | 105 ░C | Copper Alloy | 29 | Green | Dual | 3.96 mm | 0.156 in | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Female | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | 0.25 Ám | 10 Áin | |
 EDAC Inc. | Polyester Thermoplastic | 2 | 2 | Solder | 58 | Semi Bellows | Board Edge Straddle Mount | -40 C | 105 ░C | Copper Alloy | 29 | Green | Card Extender Card Guides | Dual | 3.96 mm | 0.156 in | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Tin | Female | 4-40 Flush Mount Threaded Insert Top Opening | ||||
 EDAC Inc. | Polyester Thermoplastic | 2 | 2 | Solder Eyelet(s) | 58 | Semi Bellows | Board Edge Straddle Mount | -40 C | 105 ░C | Copper Alloy | 29 | Green | Card Extender | Dual | 3.96 mm | 0.156 in | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Female | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 0.25 Ám | 10 Áin |
 EDAC Inc. | Polyester Thermoplastic | 2 | 2 | Solder | 58 | Semi Bellows | Board Edge Straddle Mount | -40 C | 105 ░C | Copper Alloy | 29 | Green | Dual | 3.96 mm | 0.156 in | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Tin | Female | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm |
