MPG06 Series

Manufacturer: Vishay General Semiconductor - Diodes Division

Catalog

DIODE GEN PURP 600V 1A MPG06

Part	Operating Temperature - Junction [Max]	Operating Temperature - Junction [Min]	Package / Case	Current - Reverse Leakage @ Vr	Voltage - Forward (Vf) (Max) @ If	Reverse Recovery Time (trr)	Voltage - DC Reverse (Vr) (Max) [Max]	Current - Average Rectified (Io)	Technology	Supplier Device Package	Speed	Speed	Mounting Type	Capacitance @ Vr, F	Grade	Qualification
Vishay General Semiconductor - Diodes Division MPG06J-E3/100	150 °C	-55 °C	MPG06 Axial	5 µA	1.1 V	600 ns	600 V	1 A	Standard	MPG06	Standard Recovery >500ns	200 mA	Through Hole	10 pF
Vishay General Semiconductor - Diodes Division MPG06J-E3/53	150 °C	-55 °C	MPG06 Axial	5 µA	1.1 V	600 ns	600 V	1 A	Standard	MPG06	Standard Recovery >500ns	200 mA	Through Hole	10 pF
Vishay General Semiconductor - Diodes Division MPG06DHE3_A/54	150 °C	-55 °C	MPG06 Axial	5 µA	1.1 V	600 ns	200 V	1 A	Standard	MPG06	Standard Recovery >500ns	200 mA	Through Hole	10 pF	Automotive	AEC-Q101
Vishay General Semiconductor - Diodes Division MPG06GHE3/54	150 °C	-55 °C	MPG06 Axial	5 µA	1.1 V	600 ns	400 V	1 A	Standard	MPG06	Standard Recovery >500ns	200 mA	Through Hole	10 pF	Automotive	AEC-Q101
Vishay General Semiconductor - Diodes Division MPG06BHE3/73	150 °C	-55 °C	MPG06 Axial	5 µA	1.1 V	600 ns	100 V	1 A	Standard	MPG06	Standard Recovery >500ns	200 mA	Through Hole	10 pF	Automotive	AEC-Q101
Vishay General Semiconductor - Diodes Division MPG06K-E3/100	150 °C	-55 °C	MPG06 Axial	5 µA	1.1 V	600 ns	800 V	1 A	Standard	MPG06	Standard Recovery >500ns	200 mA	Through Hole	10 pF
Vishay General Semiconductor - Diodes Division MPG06KHE3_A/53	150 °C	-55 °C	MPG06 Axial	5 µA	1.1 V	600 ns	800 V	1 A	Standard	MPG06	Standard Recovery >500ns	200 mA	Through Hole	10 pF	Automotive	AEC-Q101
Vishay General Semiconductor - Diodes Division MPG06B-E3/100	150 °C	-55 °C	MPG06 Axial	5 µA	1.1 V	600 ns	100 V	1 A	Standard	MPG06	Standard Recovery >500ns	200 mA	Through Hole	10 pF
Vishay General Semiconductor - Diodes Division MPG06AHE3/54	150 °C	-55 °C	MPG06 Axial	5 µA	1.1 V	600 ns	50 V	1 A	Standard	MPG06	Standard Recovery >500ns	200 mA	Through Hole	10 pF	Automotive	AEC-Q101
Vishay General Semiconductor - Diodes Division MPG06JHE3_A/100	150 °C	-55 °C	MPG06 Axial	5 µA	1.1 V	600 ns	600 V	1 A	Standard	MPG06	Standard Recovery >500ns	200 mA	Through Hole	10 pF	Automotive	AEC-Q101
