1671J Series
Manufacturer: Belden Inc.
Beta
⌘K
#24 TFE BRD TINNED COAX PVC
| Part | Conductor Material | Operating Temperature [Min] | Operating Temperature [Max] | Shield Material | Shield Coverage | Dielectric Material | VoP, Velocity of Propagation | Dielectric Diameter [diameter] | Dielectric Diameter [diameter] | Shield Type | Wire Gauge | Jacket Color | Conductor Strand | Cable Group | Jacket (Insulation) Material | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Length [x] | Length [x] | Cable Type | Length | Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | Copper Covered Silver Coated Steel | -40 C | 105 ░C | Copper Bare Copper Tinned | 100 % | Polytetrafluoroethylene (PTFE) | 70 | 1.57 mm | 0.062 in | Braid Foil | 24 AWG | Black | Solid | RG-405 | Poly-Vinyl Chloride (PVC) | 0.127 in | 3.23 mm | 152.4 m | 500 ft | Coaxial | ||
 Belden Inc. | Copper Covered Silver Coated Steel | -40 C | 105 ░C | Copper Bare Copper Tinned | 100 % | Polytetrafluoroethylene (PTFE) | 70 | 1.57 mm | 0.062 in | Braid Foil | 24 AWG | Black | Solid | RG-405 | Poly-Vinyl Chloride (PVC) | 0.127 in | 3.23 mm | Coaxial | 100 ' | 30.48 m |
