796644 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
CONN SHROUDED HEADER (4 SIDES) HDR 9 POS 5MM SOLDER RA SIDE ENTRY THRU-HOLE BOX
| Part | Insulation Height [z] | Insulation Height [z] | Contact Tail Length | Contact Tail Length | Material Flammability Rating | Contact Material | Termination Style | Operating Temperature [Min] | Operating Temperature [Max] | Header Orientation | Number of Levels | Color | Type | Contact Mating Finish | Positions Per Level | Voltage - UL | Pitch | Pitch | Number of Positions | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | 0.329 in | 8.36 mm | 0.138 in | 3.5 mm | UL94 V-0 | Copper Alloy | Solder | -40 C | 110 °C | 90° Right Angle | 1 | Green | Header Male Pins Shrouded (4 Side) | Tin | 9 | 300 V | 0.197 in | 5 mm | 9 | Through Hole |
 TE Connectivity AMP Connectors | 0.329 in | 8.36 mm | 0.138 in | 3.5 mm | UL94 V-0 | Copper Alloy | Solder | -40 C | 110 °C | 90° Right Angle | 1 | Green | Header Male Pins Shrouded (4 Side) | Tin | 18 | 300 V | 0.197 in | 5 mm | 18 | Through Hole |
 TE Connectivity AMP Connectors | 0.329 in | 8.36 mm | 0.138 in | 3.5 mm | UL94 V-0 | Copper Alloy | Solder | -40 C | 110 °C | 90° Right Angle | 1 | Green | Header Male Pins Shrouded (4 Side) | Tin | 12 | 300 V | 0.197 in | 5 mm | 12 | Through Hole |
 TE Connectivity AMP Connectors | 0.329 in | 8.36 mm | 0.138 in | 3.5 mm | UL94 V-0 | Copper Alloy | Solder | -40 C | 110 °C | 90° Right Angle | 1 | Green | Header Male Pins Shrouded (4 Side) | Tin | 23 | 300 V | 0.197 in | 5 mm | 23 | Through Hole |
 TE Connectivity AMP Connectors | 0.329 in | 8.36 mm | 0.138 in | 3.5 mm | UL94 V-0 | Copper Alloy | Solder | -40 C | 110 °C | 90° Right Angle | 1 | Green | Header Male Pins Shrouded (4 Side) | Tin | 2 | 300 V | 0.197 in | 5 mm | 2 | Through Hole |
 TE Connectivity AMP Connectors | 0.329 in | 8.36 mm | 0.138 in | 3.5 mm | UL94 V-0 | Copper Alloy | Solder | -40 C | 110 °C | 90° Right Angle | 1 | Green | Header Male Pins Shrouded (4 Side) | Tin | 5 | 300 V | 0.197 in | 5 mm | 5 | Through Hole |
TE Connectivity AMP Connectors | 0.329 in | 8.36 mm | 0.138 in | 3.5 mm | UL94 V-0 | Copper Alloy | Solder | -40 C | 110 °C | 90° Right Angle | 1 | Green | Header Male Pins Shrouded (4 Side) | Tin | 20 | 300 V | 0.197 in | 5 mm | 20 | Through Hole |
 TE Connectivity AMP Connectors | 0.329 in | 8.36 mm | 0.138 in | 3.5 mm | UL94 V-0 | Copper Alloy | Solder | -40 C | 110 °C | 90° Right Angle | 1 | Green | Header Male Pins Shrouded (4 Side) | Tin | 8 | 300 V | 0.197 in | 5 mm | 8 | Through Hole |
 TE Connectivity AMP Connectors | 0.329 in | 8.36 mm | 0.138 in | 3.5 mm | UL94 V-0 | Copper Alloy | Solder | -40 C | 110 °C | 90° Right Angle | 1 | Green | Header Male Pins Shrouded (4 Side) | Tin | 6 | 300 V | 0.197 in | 5 mm | 6 | Through Hole |
 TE Connectivity AMP Connectors | 0.329 in | 8.36 mm | 0.138 in | 3.5 mm | UL94 V-0 | Copper Alloy | Solder | -40 C | 110 °C | 90° Right Angle | 1 | Green | Header Male Pins Shrouded (4 Side) | Tin | 13 | 300 V | 0.197 in | 5 mm | 13 | Through Hole |
