SRMX6DUW00D01GE Series

Catalog

SBC 1.0GHZ 2 CORE 1GB/- RAM

Part	Speed	Operating Temperature [Max]	Operating Temperature [Min]	Contents	Storage Interface	Ethernet	Core Processor	USB	RAM Capacity/Installed	RAM Capacity/Installed	Video Outputs	Number of Cores	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Expansion Site/Bus	Form Factor	Ethernet	Cooling Type	Digital I/O Lines
SolidRun LTD SRMX6DUW00D01GE008X00CE	1 GHz	70 °C	0 °C	SD Card	eMMC eSATA uSD	10 Mbps 100 Mbps 1000 Mbps	ARM Cortex-A9 i.MX6Dual	USB 2.0 (2) USB Micro (1)	-	1 GB	HDMI SPDIF	2	50 mm	1.97 "	1.97 in	50 mm
SolidRun LTD SRMX6DUW00D01GE128G01CE	1 GHz	70 °C	0 °C		eMMC microSD		ARM Cortex-A9	USB 2.0 (4)		0 GB 1 GB	HDMI MIPI-DSI	2	100 mm	3.937 "	2.756 in	70 mm	GPIO MIPI CSI MIPI DSI mPCIe UART	SBC	RJ45 (10/100/1000)
SolidRun LTD SRMX6DUW00D01GE000G01CH	1 GHz	70 °C	0 °C		eMMC microSD		ARM Cortex-A9	USB 2.0 (4)		0 GB 1 GB	HDMI MIPI-DSI	2	100 mm	3.937 "	2.756 in	70 mm	GPIO MIPI CSI MIPI DSI mPCIe UART	SBC	RJ45 (10/100/1000)	Heat Sink
SolidRun LTD SRMX6DUW00D01GE000E01CH	1 GHz	70 °C	0 °C		eMMC M.2 microSD		ARM Cortex-A9	USB 2.0 (4)		0 GB 1 GB	HDMI LVDS MIPI DSI	2	100 mm	3.937 "	2.756 in	70 mm	GPIO LVDS M.2 MIPI CSI MIPI DSI mPCIe UART	SBC	RJ45 (10/100/1000)	Heat Sink
SolidRun LTD SRMX6DUW00D01GE128E01IE	1 GHz	85 °C	-40 C		eMMC M.2 microSD		ARM Cortex-A9	USB 2.0 (4)		0 GB 1 GB	HDMI LVDS MIPI DSI	2	100 mm	3.937 "	2.756 in	70 mm	GPIO LVDS M.2 MIPI CSI MIPI DSI mPCIe UART	SBC	RJ45 (10/100/1000)
SolidRun LTD SRMX6DUW00D01GE128E01CH	1 GHz	70 °C	0 °C		eMMC M.2 microSD		ARM Cortex-A9	USB 2.0 (4)		0 GB 1 GB	HDMI LVDS MIPI DSI	2	100 mm	3.937 "	2.756 in	70 mm	GPIO LVDS M.2 MIPI CSI MIPI DSI mPCIe UART	SBC	RJ45 (10/100/1000)	Heat Sink
SolidRun LTD SRMX6DUW00D01GE064V20I0	1 GHz	85 °C	-40 C		eMMC microSD		ARM Cortex-A9	USB 2.0 (4)		0 GB 1 GB	HDMI	2					Audio GPIO MIPI CSI mPCIe UART	SBC	RJ45 (10/100/1000)
SolidRun LTD SRMX6DUW00D01GE064G01CE	1 GHz	70 °C	0 °C		eMMC microSD		ARM Cortex-A9	USB 2.0 (4)		0 GB 1 GB	HDMI MIPI-DSI	2	100 mm	3.937 "	2.756 in	70 mm	GPIO MIPI CSI MIPI DSI mPCIe UART	SBC	RJ45 (10/100/1000)
SolidRun LTD SRMX6DUW00D01GE064E01CH	1 GHz	70 °C	0 °C		eMMC M.2 microSD		ARM Cortex-A9	USB 2.0 (4)		0 GB 1 GB	HDMI LVDS MIPI DSI	2	100 mm	3.937 "	2.756 in	70 mm	GPIO LVDS M.2 MIPI CSI MIPI DSI mPCIe UART	SBC	RJ45 (10/100/1000)	Heat Sink
SolidRun LTD SRMX6DUW00D01GE008E00IH	1.2 GHz				eSATA M.2 uSD	10 Mbps 100 Mbps 1000 Mbps	ARM Cortex-A9 i.MX6Dual	USB 2.0 (4)		1 GB 4 GB	HDMI LVDS MIPI	2	102.1 mm	4.02 in	2.72 "	69.08 mm	mPCIe				36
