1757824 Series
Manufacturer: TE Connectivity Aerospace, Defense and Marine
Beta
⌘K
CONN D-SUB HD HOUSING RCPT 62POS
| Part | Contact Type | Connector Type | Shell Finish Thickness | Shell Finish Thickness | Shell Material, Finish | Number of Positions | Number of Rows | Operating Temperature [Min] | Operating Temperature [Max] | Connector Style | Flange Feature | Mounting Type | Shell Size, Connector Layout | Note | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Current Rating (Amps) | Contact Finish | Termination | Contact Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity Aerospace, Defense and Marine | Signal | Receptacle for Female Contacts | 5.08 µm | 200 µin | Steel Yellow Chromate Plated Zinc | 62 | 3 | -50 °C | 125 °C | D-Sub High Density | Housing/Shell (Unthreaded) | Free Hanging (In-Line) | 4 | Contacts Not Included | |||||||
 TE Connectivity Aerospace, Defense and Marine | Signal | Receptacle for Female Contacts | 5.08 µm | 200 µin | Steel Yellow Chromate Plated Zinc | 15 | 3 | -50 °C | 125 °C | D-Sub High Density | Housing/Shell (Unthreaded) | Free Hanging (In-Line) | Contacts Not Included | DE E | 1 | High Density | |||||
 TE Connectivity Aerospace, Defense and Marine | Signal | Receptacle for Female Contacts | 5.08 µm | 200 µin | Steel Yellow Chromate Plated Zinc | 104 | 5 | -50 °C | 125 °C | D-Sub High Density | Housing/Shell (Unthreaded) | Free Hanging (In-Line) | 6 | Contacts Not Included | |||||||
 TE Connectivity Aerospace, Defense and Marine | Signal | Receptacle Female Sockets | Steel Yellow Chromate Plated Zinc | 78 | -55 °C | 125 °C | D-Sub High Density | Housing/Shell (Unthreaded) | Free Hanging (In-Line) | 7.5 A | Gold | Crimp | |||||||||
 TE Connectivity Aerospace, Defense and Marine | Signal | Receptacle Female Sockets | Steel Yellow Chromate Plated Zinc | 62 | 3 | -55 °C | 125 °C | D-Sub High Density | Housing/Shell (Unthreaded) | Free Hanging (In-Line) | 4 | 7.5 A | Gold | Crimp | Copper Alloy |
