325-014 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 14POS 0.100
| Part | Material - Insulation | Termination Rows [custom] | Gender | Mounting Type | Card Type | Operating Temperature [Min] | Operating Temperature [Max] | Flange Feature | Contact Finish Thickness | Contact Finish Thickness | Number of Positions/Bay/Row | Color | Read Out | Contact Finish | Termination | Number of Positions | Number of Rows [custom] | Card Thickness | Card Thickness | Contact Material | Pitch | Pitch | Contact Type | Termination Rows | Flange Feature [diameter] | Flange Feature [diameter] | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Female | Through Hole | Non Specified - Dual Edge | -65 ░C | 125 °C | 4-40 Flush Mount Threaded Insert Top Opening | 0.25 Ám | 10 Áin | 7 | Green | Dual | Gold | Solder | 14 | 2 | 3.18 mm | 0.125 in | Copper Alloy | 0.1 " | 2.54 mm | Cantilever | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Female | Through Hole | Non Specified - Single Edge | -65 ░C | 125 °C | Flush Mount Top Opening Unthreaded | 0.25 Ám | 10 Áin | 14 | Green | Single | Gold | Solder | 14 | 3.18 mm | 0.125 in | Copper Alloy | 0.1 " | 2.54 mm | Cantilever | 1 | 0.16 " | 4.06 mm | 1 | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Female | Through Hole | Non Specified - Dual Edge | -65 ░C | 125 °C | 0.25 Ám | 10 Áin | 7 | Green | Dual | Gold | Solder | 14 | 2 | 3.18 mm | 0.125 in | Copper Alloy | 0.1 " | 2.54 mm | Cantilever | |||||
EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Female | Through Hole | Non Specified - Dual Edge | -65 ░C | 125 °C | Flush Mount Top Opening Unthreaded | 0.25 Ám | 10 Áin | 7 | Green | Dual | Gold | Wire Wrap | 14 | 2 | 3.18 mm | 0.125 in | Copper Alloy | 0.1 " | 2.54 mm | Cantilever | 0.16 " | 4.06 mm | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Female | Through Hole | Non Specified - Dual Edge | -65 ░C | 125 °C | Flush Mount M3 Threaded Insert Top Opening | 0.25 Ám | 10 Áin | 7 | Green | Dual | Gold | Solder Eyelet(s) | 14 | 2 | 3.18 mm | 0.125 in | Copper Alloy | 0.1 " | 2.54 mm | Cantilever | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Female | Through Hole | Non Specified - Dual Edge | -65 ░C | 125 °C | Flush Mount M3 Threaded Insert Top Opening | 0.25 Ám | 10 Áin | 7 | Green | Dual | Gold | Wire Wrap | 14 | 2 | 3.18 mm | 0.125 in | Copper Alloy | 0.1 " | 2.54 mm | Cantilever | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Female | Through Hole | Non Specified - Dual Edge | -65 ░C | 125 °C | Flush Mount Top Opening Unthreaded | 0.25 Ám | 10 Áin | 7 | Green | Dual | Gold | Solder Eyelet(s) | 14 | 2 | 3.18 mm | 0.125 in | Copper Alloy | 0.1 " | 2.54 mm | Cantilever | 0.16 " | 4.06 mm | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | Female | Through Hole | Non Specified - Single Edge | -65 ░C | 125 °C | 4-40 Flush Mount Threaded Insert Top Opening | 0.25 Ám | 10 Áin | 14 | Green | Single | Gold | Solder | 14 | 3.18 mm | 0.125 in | Copper Alloy | 0.1 " | 2.54 mm | Cantilever | 1 | 1 | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Female | Through Hole | Non Specified - Single Edge | -65 ░C | 125 °C | 0.25 Ám | 10 Áin | 14 | Green | Single | Gold | Wire Wrap | 14 | 3.18 mm | 0.125 in | Copper Alloy | 0.1 " | 2.54 mm | Cantilever | 1 | 1 | |||||
EDAC Inc. | Diallyl Phthalate (DAP) | Female | Through Hole | Non Specified - Single Edge | -65 ░C | 125 °C | Flush Mount Top Opening Unthreaded | 0.25 Ám | 10 Áin | 14 | Green | Single | Gold | Wire Wrap | 14 | 3.18 mm | 0.125 in | Copper Alloy | 0.1 " | 2.54 mm | Cantilever | 1 | 0.16 " | 4.06 mm | 1 |
