S11MAC-P Series

Manufacturer: ODU

Catalog

ODU MEDI-SNAP METAL, STRAIGHT PL

Part	Orientation	Contact Finish - Mating	Shell Size - Insert	Shielding	Fastening Type	Backshell Material, Plating	Operating Temperature [Max]	Operating Temperature [Min]	Voltage Rating	Current Rating (Amps)	Mounting Type	Features	Connector Type	Contact Material	Insert Material	Shell Material	Applications	Number of Positions	Primary Material	Material Flammability Rating	Cable Opening	Cable Opening [Max]	Cable Opening [Min]	Color	Shell Finish	Ingress Protection	Cable Opening [Max]	Cable Opening [Min]	Cable Opening [Max]
ODU S11MAC-P12MCC9-5280	A	Gold	1	Unshielded	Detent Lock Push-Pull	Brass Chrome	120 °C	-50 °C	25 V	4 A	Free Hanging (In-Line)	Backshell	Plug Male Pins	Brass	Polyetheretherketone (PEEK)	Brass	Industrial Medical Testing Equipment & Measurement	12	Metal	UL94 V-0	4 mm 5.2 mm	0.205 in	0.157 in	Black Silver	Chrome	IP50 - Dust Protected
ODU S11MAC-P06MFG0-6570	A	Gold	1	Unshielded	Detent Lock Push-Pull	Brass Chrome	120 °C	-50 °C	33 V	7.5 A	Free Hanging (In-Line)	Backshell	Plug Male Pins	Brass	Polyetheretherketone (PEEK)	Brass	Industrial Medical Testing Equipment & Measurement	6	Metal	UL94 V-0		0.256 in	0.209 in	Gray Silver	Chrome	IP50 - Dust Protected	6.5 mm	5.3 mm
ODU S11MAC-P06MFG0-6530	A	Gold	1	Unshielded	Detent Lock Push-Pull	Brass Chrome	120 °C	-50 °C	33 V	7.5 A	Free Hanging (In-Line)	Backshell	Plug Male Pins	Brass	Polyetheretherketone (PEEK)	Brass	Industrial Medical Testing Equipment & Measurement	6	Metal	UL94 V-0		0.256 in	0.209 in	Silver White	Chrome	IP50 - Dust Protected	6.5 mm	5.3 mm
ODU S11MAC-P05MJG0-6570	A	Gold	1	Unshielded	Detent Lock Push-Pull	Brass Chrome	120 °C	-50 °C	35 V	7.5 A	Free Hanging (In-Line)	Backshell	Plug Male Pins	Brass	Polyetheretherketone (PEEK)	Brass	Industrial Medical Testing Equipment & Measurement	5	Metal	UL94 V-0		0.256 in	0.209 in	Gray Silver	Chrome	IP50 - Dust Protected	6.5 mm	5.3 mm
ODU S11MAC-P02MPH0-5240	A	Gold	1	Unshielded	Detent Lock Push-Pull	Brass Chrome	120 °C	-50 °C	48 VDC	12 Amps	Free Hanging (In-Line)	Backshell	Plug Male Pins	Brass	Polyetheretherketone (PEEK)	Brass	Industrial Medical Testing Equipment & Measurement	2	Metal	UL94 V-0	4 mm 5.2 mm	0.205 in	0.157 in		Chrome	IP50 - Dust Protected
ODU S11MAC-P12MCC9-5270	A	Gold	1	Unshielded	Detent Lock Push-Pull	Brass Chrome	120 °C	-50 °C	25 V	4 A	Free Hanging (In-Line)	Backshell	Plug Male Pins	Brass	Polyetheretherketone (PEEK)	Brass	Industrial Medical Testing Equipment & Measurement	12	Metal	UL94 V-0	4 mm 5.2 mm	0.205 in	0.157 in	Gray Silver	Chrome	IP50 - Dust Protected
ODU S11MAC-P12MCC9-6550	A	Gold	1	Unshielded	Detent Lock Push-Pull	Brass Chrome	120 °C	-50 °C	25 V	4 A	Free Hanging (In-Line)	Backshell	Plug Male Pins	Brass	Polyetheretherketone (PEEK)	Brass	Industrial Medical Testing Equipment & Measurement	12	Metal	UL94 V-0		0.256 in	0.209 in	Green Silver	Chrome	IP50 - Dust Protected	6.5 mm	5.3 mm
ODU S11MAC-P04MJG0-6580	A	Gold	1	Unshielded	Detent Lock Push-Pull	Brass Chrome	120 °C	-50 °C	48 VDC	7.5 A	Free Hanging (In-Line)	Backshell	Plug Male Pins	Brass	Polyetheretherketone (PEEK)	Brass	Industrial Medical Testing Equipment & Measurement	4	Metal	UL94 V-0		0.256 in	0.209 in	Black Silver	Chrome	IP50 - Dust Protected	6.5 mm	5.3 mm
ODU S11MAC-P04MJG0-3960	A	Gold	1	Unshielded	Detent Lock Push-Pull	Brass Chrome	120 °C	-50 °C	48 VDC	7.5 A	Free Hanging (In-Line)	Backshell	Plug Male Pins	Brass	Polyetheretherketone (PEEK)	Brass	Industrial Medical Testing Equipment & Measurement	4	Metal	UL94 V-0		0.154 in	0.106 in	Blue Silver	Chrome	IP50 - Dust Protected		2.7 mm	3.9 mm
ODU S11MAC-P08MFG0-3970	A	Gold	1	Unshielded	Detent Lock Push-Pull	Brass Chrome	120 °C	-50 °C	10 V	7.5 A	Free Hanging (In-Line)	Backshell	Plug Male Pins	Brass	Polyetheretherketone (PEEK)	Brass	Industrial Medical Testing Equipment & Measurement	8	Metal	UL94 V-0		0.154 in	0.106 in	Gray Silver	Chrome	IP50 - Dust Protected		2.7 mm	3.9 mm
