846-074 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 74POS 0.125
| Part | Termination Rows [custom] | Material - Insulation | Features | Contact Material | Contact Type | Gender | Termination | Mounting Type | Card Thickness [Max] | Card Thickness [Min] | Card Type | Pitch | Pitch | Read Out | Number of Rows [custom] | Contact Finish | Operating Temperature [Max] | Operating Temperature [Min] | Color | Number of Positions/Bay/Row | Contact Finish Thickness | Contact Finish Thickness | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Number of Positions |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Card Extender | Copper Alloy | Cantilever | Female | Solder Eyelet(s) | Board Edge Straddle Mount | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 3.18 mm | 0.125 in | Dual | 2 | Gold | 125 °C | -40 C | Green | 37 | 0.25 Ám | 10 Áin | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | 74 |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Copper Alloy | Cantilever | Female | Solder | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 3.18 mm | 0.125 in | Dual | 2 | Gold | 125 °C | -40 C | Green | 37 | 0.25 Ám | 10 Áin | 0.128 " | 3.25 mm | 74 | ||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Copper Alloy | Cantilever | Female | Solder Eyelet(s) | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 3.18 mm | 0.125 in | Dual | 2 | Gold | 125 °C | -40 C | Green | 37 | 0.25 Ám | 10 Áin | 0.156 " | 3.96 mm | 74 | ||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Card Extender | Copper Alloy | Cantilever | Female | Solder | Board Edge Straddle Mount | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 3.18 mm | 0.125 in | Dual | 2 | Gold | 125 °C | -40 C | Green | 37 | 0.25 Ám | 10 Áin | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | 74 |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Copper Alloy | Cantilever | Female | Wire Wrap | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 3.18 mm | 0.125 in | Dual | 2 | Gold | 125 °C | -40 C | Green | 37 | 0.25 Ám | 10 Áin | Flush Mount M3 Threaded Insert Top Opening | 74 | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Card Extender | Copper Alloy | Cantilever | Female | Solder | Board Edge Straddle Mount | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 3.18 mm | 0.125 in | Dual | 2 | Gold | 125 °C | -40 C | Green | 37 | 0.25 Ám | 10 Áin | 0.156 " | 3.96 mm | 74 | |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Copper Alloy | Cantilever | Female | Solder Eyelet(s) | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 3.18 mm | 0.125 in | Dual | 2 | Gold | 125 °C | -40 C | Green | 37 | 0.25 Ám | 10 Áin | 74 | ||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Copper Alloy | Cantilever | Female | Wire Wrap | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 3.18 mm | 0.125 in | Dual | 2 | Gold | 125 °C | -40 C | Green | 37 | 0.25 Ám | 10 Áin | 4-40 Flush Mount Threaded Insert Top Opening | 74 | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Card Extender | Copper Alloy | Cantilever | Female | Solder | Board Edge Straddle Mount | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 3.18 mm | 0.125 in | Dual | 2 | Gold | 125 °C | -40 C | Green | 37 | 0.25 Ám | 10 Áin | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | 74 |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Copper Alloy | Cantilever | Female | Solder | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 3.18 mm | 0.125 in | Dual | 2 | Gold | 125 °C | -40 C | Green | 37 | 0.25 Ám | 10 Áin | 4-40 Flush Mount Threaded Insert Top Opening | 74 |
