858-004 Series
Manufacturer: NorComp Inc.
Beta
⌘K
CONN PLUG FMALE 4POS SOLDER CUP
| Part | Current Rating (Amps) | Insert Material | Primary Material | Mounting Type | Color | Shell Material | Shielding | Contact Finish - Mating | Operating Temperature [Max] | Operating Temperature [Min] | Number of Positions | Applications | Orientation | Voltage Rating | Material Flammability Rating | Fastening Type | Shell Size - Insert | Ingress Protection | Connector Type | Contact Material | Contact Finish Thickness - Mating | Shell Finish | Features | Cable Opening | Cable Opening | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Backshell Material, Plating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
NorComp Inc. | 4 A | Polybutylene Terephthalate (PBT) | Metal | Free Hanging (In-Line) | Black Silver | Brass | Shielded | Gold | 85 °C | -40 C | 4 | Industrial Medical | A | 250 V | UL94 V-0 | Threaded | M12-4 | IP67 - Dust Tight Waterproof | Plug Female Sockets | Brass | Flash | Nickel | Coupling Nut | |||||
 NorComp Inc. | 4 A | Polybutylene Terephthalate (PBT) | Metal | Free Hanging (In-Line) | Silver | Brass | Shielded | Gold | 85 °C | -40 C | 4 | Industrial Medical | A | 250 V | UL94 V-0 | Threaded | M12-4 | IP67 - Dust Tight Waterproof | Receptacle Male Pins | Brass | Flash | Nickel | 0.394 in | 10 mm | ||||
NorComp Inc. | 4 A | Polybutylene Terephthalate (PBT) | Metal | Free Hanging (In-Line) | Silver | Brass | Shielded | Gold | 85 °C | -40 C | 4 | Industrial Medical | A | 250 V | UL94 V-0 | Threaded | M12-4 | IP67 - Dust Tight Waterproof | Receptacle Male Pins | Brass | Nickel | 0.394 in | 10 mm | 0.25 µm | 10 µin | |||
NorComp Inc. | 4 A | Polybutylene Terephthalate (PBT) | Metal | Free Hanging (In-Line) | Silver | Aluminum Alloy | Gold | 85 °C | -40 C | 4 | Industrial Medical | A | 250 V | UL94 V-0 | Threaded | M12-4 | IP67 - Dust Tight Waterproof | Receptacle Male Pins | Brass | Nickel | Backshell Strain Relief | 0.25 µm | 10 µin | Aluminum Alloy Nickel | ||||
 NorComp Inc. | 4 A | Polybutylene Terephthalate (PBT) | Metal | Free Hanging (In-Line) | Black Silver | Brass | Unshielded | Gold | 85 °C | -40 C | 4 | Industrial Medical | A | 250 V | UL94 V-0 | Threaded | M12-4 | IP67 - Dust Tight Waterproof | Receptacle Male Pins | Brass | Nickel | 0.25 µm | 10 µin | |||||
 NorComp Inc. | 4 A | Polybutylene Terephthalate (PBT) | Metal | Free Hanging (In-Line) | Black Silver | Brass | Unshielded | Gold | 85 °C | -40 C | 4 | Industrial Medical | A | 250 V | UL94 V-0 | Threaded | M12-4 | IP67 - Dust Tight Waterproof | Plug Female Sockets | Brass | Flash | Nickel | Coupling Nut |
