CI5202P1 Series
Manufacturer: Cvilux USA
Beta
⌘K
2 POS 3.96MM(.156) WIRE TO BOARD
| Part | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Insulation Height | Insulation Height | Contact Length - Mating | Contact Length - Mating | Contact Material | Current Rating (Amps) | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Contact Shape | Insulation Material | Connector Type | Material Flammability Rating | Number of Positions | Contact Type | Contact Length - Post [x] | Contact Length - Post [x] | Number of Positions Loaded | Termination | Shrouding | Insulation Color | Style | Operating Temperature [Max] | Operating Temperature [Min] | Voltage Rating | Fastening Type | Overall Contact Length [x] | Overall Contact Length [x] | Contact Finish - Post | Pitch - Mating | Pitch - Mating | Mounting Type | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Cvilux USA | 120 Áin | 3.05 Ám | 9.4 mm | 0.37 in | 0.303 in | 7.7 mm | Brass | 7 A | 120 µin | 3.05 µm | Square | Nylon 4/6 Polyamide (PA46) | Header | UL94 V-0 | 2 | Male Pin | 3.7 mm | 0.146 " | All | Solder | Shrouded - 1 Wall | Natural | Board to Cable/Wire | 105 ░C | -25 °C | 250 VAC | Locking Ramp | 14.6 mm | 0.575 in | Tin | 3.96 mm | 0.156 in | Through Hole | 1 |
