DNH10 Series
Manufacturer: Panduit Corp
Beta
⌘K
CONN QC RCPT 10-12AWG 0.250
| Part | Insulation Diameter [diameter] | Insulation Diameter [diameter] | Color | Mounting Type | Tab Width [x] | Tab Width [x] | Contact Material | Wire Gauge [Min] | Wire Gauge [Max] | Termination | Insulation | Gender | Length - Overall [x] | Length - Overall [x] | Terminal Type | Contact Finish | Tab Thickness | Tab Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Panduit Corp | 5.84 mm | 0.23 in | Yellow | Free Hanging (In-Line) | 6.35 mm | 0.25 in | Brass | 10 AWG | 12 AWG | Crimp | Fully Insulated Heat Shrink | Female | 1.44 in | 36.58 mm | Standard | Tin | 0.81 mm | 0.032 in |
