892-031 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 31POS 0.100
| Part | Material - Insulation | Termination Rows | Number of Positions/Bay/Row [custom] | Color | Card Thickness [Max] | Card Thickness [Min] | Read Out | Contact Finish | Pitch | Pitch | Operating Temperature [Max] | Operating Temperature [Min] | Gender | Mounting Type | Termination | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Number of Rows | Contact Material | Number of Positions [custom] | Contact Finish Thickness | Contact Finish Thickness | Contact Type | Card Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 31 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Gold | 0.1 " | 2.54 mm | 125 °C | -40 C | Female | Right Angle Through Hole | Solder | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 1 | Copper Alloy | 31 | 0.25 Ám | 10 Áin | Cantilever | Non Specified - Single Edge |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 31 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Gold | 0.1 " | 2.54 mm | 125 °C | -40 C | Female | Right Angle Through Hole | Solder | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | 1 | Copper Alloy | 31 | 0.25 Ám | 10 Áin | Cantilever | Non Specified - Single Edge |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 31 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Gold | 0.1 " | 2.54 mm | 125 °C | -40 C | Female | Through Hole | Wire Wrap | Flush Mount M3 Threaded Insert Top Opening | 1 | Copper Alloy | 31 | 0.25 Ám | 10 Áin | Cantilever | Non Specified - Single Edge | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 31 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Gold | 0.1 " | 2.54 mm | 125 °C | -40 C | Female | Through Hole | Solder | 1 | Copper Alloy | 31 | 0.25 Ám | 10 Áin | Cantilever | Non Specified - Single Edge | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 31 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Gold | 0.1 " | 2.54 mm | 125 °C | -40 C | Female | Through Hole | Wire Wrap | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | 1 | Copper Alloy | 31 | 0.25 Ám | 10 Áin | Cantilever | Non Specified - Single Edge |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 31 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Gold | 0.1 " | 2.54 mm | 125 °C | -40 C | Female | Through Hole | Wire Wrap | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | 1 | Copper Alloy | 31 | 0.25 Ám | 10 Áin | Cantilever | Non Specified - Single Edge |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 31 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Gold | 0.1 " | 2.54 mm | 125 °C | -40 C | Female | Through Hole | Solder | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | 1 | Copper Alloy | 31 | 0.25 Ám | 10 Áin | Cantilever | Non Specified - Single Edge |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 31 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Gold | 0.1 " | 2.54 mm | 125 °C | -40 C | Female | Through Hole | Solder | 4-40 Flush Mount Threaded Insert Top Opening | 1 | Copper Alloy | 31 | 0.25 Ám | 10 Áin | Cantilever | Non Specified - Single Edge | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 31 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Gold | 0.1 " | 2.54 mm | 125 °C | -40 C | Female | Through Hole | Solder | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 1 | Copper Alloy | 31 | 0.25 Ám | 10 Áin | Cantilever | Non Specified - Single Edge |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 31 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Gold | 0.1 " | 2.54 mm | 125 °C | -40 C | Female | Through Hole | Wire Wrap | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | 1 | Copper Alloy | 31 | 0.25 Ám | 10 Áin | Cantilever | Non Specified - Single Edge |
