A3CCH Series

Manufacturer: TE Connectivity AMP Connectors

Catalog

IDC CABLE - AKC26H/AE26M/AKC26H

Part	Pitch - Cable	Pitch - Cable	Cable Termination	Connector Type	Number of Positions	Shielding	Contact Finish	Number of Rows [custom]	Color	Features	Pitch - Connector	Pitch - Connector	Contact Finish Thickness	Contact Finish Thickness	Length [x]	Length [x]	Length	Length	Length
TE Connectivity AMP Connectors A3CCH-2618M	0.05 in	1.27 mm	IDC	Socket to Socket	26	Unshielded	Gold	2	Multiple Ribbon	Polarizing Key	0.1 in	2.54 mm	0.38 µm	15 µin	457.2 mm	1.5 ft
TE Connectivity AMP Connectors A3CCH-6036M	0.05 in	1.27 mm	IDC	Socket to Socket	60	Unshielded	Gold	2	Multiple Ribbon	Polarizing Key	0.1 in	2.54 mm	0.38 µm	15 µin			91.44 cm	3 ft
TE Connectivity AMP Connectors A3CCH-4018G	0.05 in	1.27 mm	IDC	Socket to Socket	40	Unshielded	Gold	2		Polarizing Key	0.1 in	2.54 mm	0.38 µm	15 µin	457.2 mm	1.5 ft
TE Connectivity AMP Connectors A3CCH-1036M	0.05 in	1.27 mm	IDC	Socket to Socket	10	Unshielded	Gold	2	Multiple Ribbon	Polarizing Key	0.1 in	2.54 mm	0.38 µm	15 µin			91.44 cm	3 ft
TE Connectivity AMP Connectors A3CCH-6406G	0.05 in	1.27 mm	IDC	Socket to Socket	64	Unshielded	Gold	2		Polarizing Key	0.1 in	2.54 mm	0.38 µm	15 µin			152.4 mm	0.5 '	6 "
TE Connectivity AMP Connectors A3CCH-4406G	0.05 in	1.27 mm	IDC	Socket to Socket	44	Unshielded	Gold	2		Polarizing Key	0.1 in	2.54 mm	0.38 µm	15 µin			152.4 mm	0.5 '	6 "
TE Connectivity AMP Connectors A3CCH-1636G	0.05 in	1.27 mm	IDC	Socket to Socket	16	Unshielded	Gold	2		Polarizing Key	0.1 in	2.54 mm	0.38 µm	15 µin			91.44 cm	3 ft
TE Connectivity AMP Connectors A3CCH-5036G	0.05 in	1.27 mm	IDC	Socket to Socket	50	Unshielded	Gold	2		Polarizing Key	0.1 in	2.54 mm	0.38 µm	15 µin			91.44 cm	3 ft
TE Connectivity AMP Connectors A3CCH-6418G	0.05 in	1.27 mm	IDC	Socket to Socket	64	Unshielded	Gold	2		Polarizing Key	0.1 in	2.54 mm	0.38 µm	15 µin	457.2 mm	1.5 ft
TE Connectivity AMP Connectors A3CCH-3036G	0.05 in	1.27 mm	IDC	Socket to Socket	30	Unshielded	Gold	2		Polarizing Key	0.1 in	2.54 mm	0.38 µm	15 µin			91.44 cm	3 ft
