8115 Series
Manufacturer: Belden Inc.
Beta
⌘K
MULTI-PAIR 30COND 24AWG
| Part | Shield Material | Shield Coverage | Usage | Shield Type | Features | Ratings | Wire Gauge | Conductor Insulation | Operating Temperature [Max] | Operating Temperature [Min] | Number of Conductors | Length | Length | Jacket (Insulation) Material | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Conductor Strand [custom] | Conductor Strand [custom] | Jacket Color | Conductor Material | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Cable Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | Aluminum Copper Tinned | 65 % 100 % | Computer | Braid Foil | Drain Wire | UL Style 2919 | 24 AWG | Foam Polyethylene (FPE) | 80 °C | -30 ░C | 30 | 304.8 m | 1000 ft | Poly-Vinyl Chloride (PVC) | 1.016 mm | 0.04 in | 7 | 32 AWG | Chrome | Copper Tinned | 12.12 mm | 0.477 " | Multi-Pair |
