887-009 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 9POS 0.156
| Part | Material - Insulation | Termination Rows | Number of Positions/Bay/Row | Color | Pitch | Pitch | Number of Rows | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Mounting Type | Card Type | Contact Finish | Gender | Termination | Number of Positions | Contact Type | Contact Finish Thickness | Contact Finish Thickness | Card Thickness [Max] | Card Thickness [Min] | Operating Temperature [Max] | Operating Temperature [Min] | Read Out | Contact Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 9 | Black | 3.96 mm | 0.156 in | 1 | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Through Hole | Non Specified - Single Edge | Gold | Female | Solder | 9 | Cantilever | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Single | Copper Alloy |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 9 | Black | 3.96 mm | 0.156 in | 1 | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | Through Hole | Non Specified - Single Edge | Gold | Female | Solder | 9 | Cantilever | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Single | Copper Alloy |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 9 | Black | 3.96 mm | 0.156 in | 1 | M3 Threaded Insert Top Mount Opening | Through Hole | Non Specified - Single Edge | Gold | Female | Solder | 9 | Cantilever | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Single | Copper Alloy | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 9 | Black | 3.96 mm | 0.156 in | 1 | 0.116 " | Floating Bobbin Top Mount Opening | 2.95 mm | Through Hole | Non Specified - Single Edge | Gold | Female | Wire Wrap | 9 | Cantilever | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Single | Copper Alloy |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 9 | Black | 3.96 mm | 0.156 in | 1 | 0.128 " | Side Mount Opening Unthreaded | 3.25 mm | Right Angle Through Hole | Non Specified - Single Edge | Gold | Female | Solder | 9 | Cantilever | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Single | Copper Alloy |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 9 | Black | 3.96 mm | 0.156 in | 1 | Flush Mount M3 Threaded Insert Top Opening | Through Hole | Non Specified - Single Edge | Gold | Female | Solder Eyelet(s) | 9 | Cantilever | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Single | Copper Alloy | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 9 | Black | 3.96 mm | 0.156 in | 1 | 0.128 " | Side Mount Opening Unthreaded | 3.25 mm | Through Hole | Non Specified - Single Edge | Gold | Female | Solder | 9 | Cantilever | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Single | Copper Alloy |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 9 | Black | 3.96 mm | 0.156 in | 1 | 0.156 " | 3.96 mm | Through Hole | Non Specified - Single Edge | Gold | Female | Wire Wrap | 9 | Cantilever | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Single | Copper Alloy | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 9 | Black | 3.96 mm | 0.156 in | 1 | 0.116 " | Floating Bobbin Top Mount Opening | 2.95 mm | Right Angle Through Hole | Non Specified - Single Edge | Gold | Female | Solder | 9 | Cantilever | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Single | Copper Alloy |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 9 | Black | 3.96 mm | 0.156 in | 1 | 4-40 Threaded Insert Top Mount Opening | Through Hole | Non Specified - Single Edge | Gold | Female | Wire Wrap | 9 | Cantilever | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Single | Copper Alloy |
