896-006 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 6POS 0.125
| Part | Termination Rows | Material - Insulation | Contact Type | Operating Temperature [Max] | Operating Temperature [Min] | Mounting Type | Number of Positions | Card Type | Gender | Card Thickness [Max] | Card Thickness [Min] | Number of Positions/Bay/Row | Number of Rows | Contact Material | Termination | Read Out | Color | Pitch | Pitch | Contact Finish Thickness | Contact Finish Thickness | Contact Finish | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Cantilever | 125 °C | -40 C | Through Hole | 6 | Non Specified - Single Edge | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 6 | 1 | Copper Alloy | Solder Eyelet(s) | Single | Black | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Gold | |||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Cantilever | 125 °C | -40 C | Right Angle Through Hole | 6 | Non Specified - Single Edge | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 6 | 1 | Copper Alloy | Solder | Single | Black | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Gold | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Cantilever | 125 °C | -40 C | Right Angle Through Hole | 6 | Non Specified - Single Edge | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 6 | 1 | Copper Alloy | Solder | Single | Black | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Gold | 3.25 mm | 0.128 " | |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Cantilever | 125 °C | -40 C | Through Hole | 6 | Non Specified - Single Edge | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 6 | 1 | Copper Alloy | Wire Wrap | Single | Black | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Gold | Floating Bobbin Top Mount Opening | 2.95 mm | 0.116 " |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Cantilever | 125 °C | -40 C | Through Hole | 6 | Non Specified - Single Edge | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 6 | 1 | Copper Alloy | Wire Wrap | Single | Black | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Gold | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Cantilever | 125 °C | -40 C | Through Hole | 6 | Non Specified - Single Edge | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 6 | 1 | Copper Alloy | Solder Eyelet(s) | Single | Black | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Gold | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Cantilever | 125 °C | -40 C | Through Hole | 6 | Non Specified - Single Edge | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 6 | 1 | Copper Alloy | Solder | Single | Black | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Gold | Flush Mount Side Opening Unthreaded | 3.25 mm | 0.128 " |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Cantilever | 125 °C | -40 C | Through Hole | 6 | Non Specified - Single Edge | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 6 | 1 | Copper Alloy | Wire Wrap | Single | Black | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Gold | Flush Mount Side Opening Unthreaded | 3.25 mm | 0.128 " |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Cantilever | 125 °C | -40 C | Through Hole | 6 | Non Specified - Single Edge | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 6 | 1 | Copper Alloy | Wire Wrap | Single | Black | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Gold | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Cantilever | 125 °C | -40 C | Through Hole | 6 | Non Specified - Single Edge | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 6 | 1 | Copper Alloy | Wire Wrap | Single | Black | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Gold |
