R14170 Series
Manufacturer: Radiall USA, Inc.
Beta
⌘K
BNC / MALE-MALE ADAPTER
| Part | Body Material | Mating Cycles | Center Contact Material | Body Finish | Operating Temperature [Min] | Operating Temperature [Max] | Dielectric Material | Adapter Type | Center Gender | Convert To (Adapter End) | Center Contact Plating | Conversion Type | Adapter Series | Convert From (Adapter End) | Mounting Type | Frequency - Max [Max] | Impedance | Style | Fastening Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Radiall USA, Inc. | Brass | 500 | Brass | Nickel | -65 ░C | 165 °C | Polytetrafluoroethylene (PTFE) | Plug to Plug | Male to Male | BNC Plug Male Pin | Gold | Same Series | BNC to BNC | BNC Plug Male Pin | Free Hanging (In-Line) | 4 GHz | 50 Ohms | Straight | Bayonet Lock |
Radiall USA, Inc. | Brass | 500 | Beryllium Copper | Nickel | -65 ░C | 165 °C | Polytetrafluoroethylene (PTFE) | Jack to Jack | Female to Female | BNC Jack Female Socket | Gold | Same Series | BNC to BNC | BNC Jack Female Socket | Free Hanging (In-Line) | 4 GHz | 50 Ohms | Straight | Bayonet Lock |
 Radiall USA, Inc. | Brass | 500 | Brass | Nickel | -65 ░C | 165 °C | Polytetrafluoroethylene (PTFE) | Plug to Plug | Male to Male | BNC Plug Male Pin | Gold | Same Series | BNC to BNC | BNC Plug Male Pin | Free Hanging (In-Line) | 4 GHz | 50 Ohms | Straight | Bayonet Lock |
 Radiall USA, Inc. | Brass | 500 | Beryllium Copper | Nickel | -65 ░C | 165 °C | Polytetrafluoroethylene (PTFE) | Jack to Jack | Female to Female | BNC Jack Female Socket | Gold | Same Series | BNC to BNC | BNC Jack Female Socket | Free Hanging (In-Line) | 4 GHz | 50 Ohms | Straight | Bayonet Lock |
