PB242 Series
Manufacturer: E-Switch
Beta
⌘K
SWITCH PUSHBUTTON DPST 20A 125V
| Part | Electrical Life | Circuit | Voltage Rating - AC | Actuator Marking | Ingress Protection | Panel Cutout Dimensions [x] | Panel Cutout Dimensions [y] | Current Rating (Amps) | Color - Actuator/Cap | Mounting Type | Type | Operating Temperature [Max] | Operating Temperature [Min] | Termination Style | Actuator Type | Switch Function |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 E-Switch | 10000 Cycles | DPST | 125 V | No Marking | IP54 - Dust Protected Water Resistant | 30 mm | 22 mm | 20 A | Black | Panel Mount Snap-In | Illuminated Standard | 85 °C | -20 ░C | Quick Connect - 0.250" (6.3mm) | Button Dual Square | Off-On |
 E-Switch | 10000 Cycles | DPST | 125 V | No Marking | IP54 - Dust Protected Water Resistant | 30 mm | 22 mm | 20 A | Green Red | Panel Mount Snap-In | Illuminated Standard | 85 °C | -20 ░C | Quick Connect - 0.250" (6.3mm) | Button Dual Square | Off-On |
