178294 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
CONN HEADER R/A 4POS 3.81MM
| Part | Number of Rows | Termination | Shrouding | Contact Length - Post [x] | Contact Length - Post [x] | Number of Positions | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Number of Positions Loaded | Mounting Type | Applications | Connector Type | Insulation Color | Contact Shape | Material Flammability Rating | Contact Material | Operating Temperature [Max] | Operating Temperature [Min] | Voltage Rating | Insulation Material | Contact Type | Fastening Type | Insulation Height | Insulation Height | Pitch - Mating | Pitch - Mating | Contact Finish - Post | Style |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity Raychem Cable Protection | 1 | Solder | Shrouded - 4 Wall | 0.15 in | 3.81 mm | 4 | 78.7 µin | 2 µm | All | Through Hole Right Angle | General Purpose Industrial | Header | Black | Rectangular | UL94 V-0 | Copper Alloy | 105 ░C | -55 °C | 250 VDC | Glass Filled Polyester Thermoplastic | Tab | Detent Lock | 9.35 mm | 0.368 in | 3.81 mm | 0.15 in | Tin | Board to Board Cable |
