Q10AN6 Series
Manufacturer: BANNER ENGINEERING
Beta
⌘K
Q10 SERIES: RECEIVERRANGE: 1
| Part | Ingress Protection | Output Configuration | Response Time | Operating Temperature [Max] | Operating Temperature [Min] | Cable Length | Cable Length | Sensing Distance | Sensing Distance | Light Source | Voltage - Supply [Min] | Voltage - Supply [Max] | Sensing Method | Connection Method | Adjustment Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 BANNER ENGINEERING | IEC IEC IP67 IP67 NEMA 6P | NPN - Light-ON | 8 ms | 70 °C | -40 C | 78.74 " | 2 m | 70.866 in | 1.8 m | Infrared (880nm) | 10 VDC | 30 VDC | Through-Beam | Cable | |
 BANNER ENGINEERING | IEC IEC IP67 IP67 NEMA 6P | NPN - Light-ON | 8 ms | 70 °C | -40 C | 70.866 in | 1.8 m | Infrared (880nm) | 10 VDC | 30 VDC | Through-Beam | Connector | |||
 BANNER ENGINEERING | IEC IP67 NEMA 6P | NPN - Light-ON | 3 ms | 70 °C | -40 C | 19.685 in | 50 cm | Infrared (880nm) | 10 VDC | 30 VDC | Diffuse | Connector | Adjustable Potentiometer |
