395-033 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 33POS 0.100
| Part | Material - Insulation | Termination Rows | Color | Number of Positions/Bay/Row | Flange Feature [diameter] | Flange Feature [diameter] | Contact Material | Mounting Type | Operating Temperature [Min] | Operating Temperature [Max] | Contact Finish Thickness | Contact Finish Thickness | Gender | Card Thickness [Max] | Card Thickness [Min] | Contact Type | Contact Finish | Termination | Pitch | Pitch | Number of Positions [custom] | Number of Rows | Read Out | Card Type | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | Black | 33 | 0.156 " | 3.96 mm | Copper Alloy | Through Hole | -40 C | 105 ░C | 0.25 Ám | 10 Áin | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Gold | Solder | 0.1 " | 2.54 mm | 33 | 1 | Single | Non Specified - Single Edge | |
 EDAC Inc. | Polyester Thermoplastic | 1 | Black | 33 | 0.128 " | 3.25 mm | Copper Alloy | Through Hole | -40 C | 105 ░C | 0.25 Ám | 10 Áin | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Gold | Wire Wrap | 0.1 " | 2.54 mm | 33 | 1 | Single | Non Specified - Single Edge | |
 EDAC Inc. | Polyester Thermoplastic | 1 | Black | 33 | 0.156 " | 3.96 mm | Copper Alloy | Through Hole | -40 C | 105 ░C | 0.25 Ám | 10 Áin | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Gold | Solder | 0.1 " | 2.54 mm | 33 | 1 | Single | Non Specified - Single Edge | |
 EDAC Inc. | Polyester Thermoplastic | 1 | Black | 33 | Copper Alloy | Right Angle Through Hole | -40 C | 105 ░C | 0.25 Ám | 10 Áin | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Gold | Solder | 0.1 " | 2.54 mm | 33 | 1 | Single | Non Specified - Single Edge | 4-40 Threaded Insert Top Mount Opening | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Black | 33 | 0.128 " | 3.25 mm | Copper Alloy | Through Hole | -40 C | 105 ░C | 0.25 Ám | 10 Áin | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Gold | Solder | 0.1 " | 2.54 mm | 33 | 1 | Single | Non Specified - Single Edge | |
 EDAC Inc. | Polyester Thermoplastic | 1 | Black | 33 | 0.116 " | 2.95 mm | Copper Alloy | Right Angle Through Hole | -40 C | 105 ░C | 0.25 Ám | 10 Áin | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Gold | Solder | 0.1 " | 2.54 mm | 33 | 1 | Single | Non Specified - Single Edge | Floating Bobbin Top Mount Opening |
 EDAC Inc. | Polyester Thermoplastic | 1 | Black | 33 | 0.116 " | 2.95 mm | Copper Alloy | Through Hole | -40 C | 105 ░C | 0.25 Ám | 10 Áin | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Gold | Wire Wrap | 0.1 " | 2.54 mm | 33 | 1 | Single | Non Specified - Single Edge | Floating Bobbin Top Mount Opening |
 EDAC Inc. | Polyester Thermoplastic | 1 | Black | 33 | Copper Alloy | Through Hole | -40 C | 105 ░C | 0.25 Ám | 10 Áin | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Gold | Solder | 0.1 " | 2.54 mm | 33 | 1 | Single | Non Specified - Single Edge | 4-40 Threaded Insert Top Mount Opening | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Black | 33 | Copper Alloy | Through Hole | -40 C | 105 ░C | 0.25 Ám | 10 Áin | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Gold | Solder | 0.1 " | 2.54 mm | 33 | 1 | Single | Non Specified - Single Edge | M3 Threaded Insert Top Mount Opening | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Black | 33 | 0.128 " | 3.25 mm | Copper Alloy | Right Angle Through Hole | -40 C | 105 ░C | 0.25 Ám | 10 Áin | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Gold | Solder | 0.1 " | 2.54 mm | 33 | 1 | Single | Non Specified - Single Edge | Flush Mount Top Opening Unthreaded |
