357-012 Series
Manufacturer: EDAC Inc.
Catalog
CARD EDGE CONNECTOR ROHS COMPLIANT: YES
...
| Part | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Card Type | Mounting Type | Number of Positions/Bay/Row [custom] | Pitch [x] | Pitch [x] | Number of Rows | Termination Rows | Color | Contact Finish | Gender | Contact Finish Thickness | Contact Finish Thickness | Termination | Contact Material | Material - Insulation | Contact Type | Operating Temperature [Min] | Operating Temperature [Max] | Read Out | Card Thickness [Min] | Card Thickness [Min] | Card Thickness [Max] | Card Thickness [Max] | Number of Positions | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 0.116 in | Floating Bobbin Flush Mount | 2.95 mm | Non Specified - Dual Edge | Through Hole | 6 | 0.156 in | 3.96 mm | 2 | 2 | Black | Gold | Female | 10 Áin | 0.25 Ám | Solder Eyelet(s) | Copper Alloy | Polyester Thermoplastic | Semi Bellows | -40 °C | 105 ░C | Dual | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 12 | |
 EDAC Inc. | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | Non Specified - Dual Edge | Board Edge Straddle Mount | 6 | 0.156 in | 3.96 mm | 2 | 2 | Black | Gold | Female | 10 Áin | 0.25 Ám | Solder Eyelet(s) | Copper Alloy | Polyester Thermoplastic | Semi Bellows | -40 °C | 105 ░C | Dual | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 12 | Card Extender |
 EDAC Inc. | 0.156 in | Flush Mount Top Opening Unthreaded | 3.96 mm | Non Specified - Dual Edge | Surface Mount | 12 | 0.156 in | 3.96 mm | 2 | 1 | Black | Gold | Female | 10 Áin | 0.25 Ám | Solder Eyelet(s) | Copper Alloy | Polyester Thermoplastic | Semi Bellows | -40 °C | 105 ░C | Dual | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 24 | |
 EDAC Inc. | 4-40 Flush Mount Threaded Insert Top Opening | Non Specified - Single Edge | Through Hole Right Angle | 12 | 0.156 in | 3.96 mm | 1 | 1 | Black | Gold | Female | 10 Áin | 0.25 Ám | Solder | Copper Alloy | Polyester Thermoplastic | Semi Bellows | -40 °C | 105 ░C | Single | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 12 | Card Guides | ||
 EDAC Inc. | 4-40 Flush Mount Threaded Insert Top Opening | Non Specified - Single Edge | Through Hole | 12 | 0.156 in | 3.96 mm | 1 | 1 | Black | Tin | Female | Solder | Copper Alloy | Polyester Thermoplastic | Semi Bellows | -40 °C | 105 ░C | Single | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 12 | Card Guides | ||||
 EDAC Inc. | 4-40 Flush Mount Threaded Insert Top Opening | Non Specified - Single Edge | Through Hole | 12 | 0.156 in | 3.96 mm | 1 | 1 | Black | Gold | Female | 10 Áin | 0.25 Ám | Solder | Copper Alloy | Polyester Thermoplastic | Semi Bellows | -40 °C | 105 ░C | Single | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 12 | Card Guides | ||
 EDAC Inc. | Non Specified - Dual Edge | Through Hole Right Angle | 12 | 0.156 in | 3.96 mm | 2 | 1 | Black | Gold | Female | 10 Áin | 0.25 Ám | Solder | Copper Alloy | Polyester Thermoplastic | Semi Bellows | -40 °C | 105 ░C | Dual | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 24 | ||||
 EDAC Inc. | Flush Mount M3 Threaded Insert Top Opening | Non Specified - Dual Edge | Through Hole | 6 | 0.156 in | 3.96 mm | 2 | 2 | Black | Tin | Female | Solder | Copper Alloy | Polyester Thermoplastic | Semi Bellows | -40 °C | 105 ░C | Dual | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 12 | |||||
 EDAC Inc. | 4-40 Flush Mount Threaded Insert Top Opening | Non Specified - Single Edge | Through Hole | 12 | 0.156 in | 3.96 mm | 1 | 1 | Black | Gold | Female | 10 Áin | 0.25 Ám | Solder | Copper Alloy | Polyester Thermoplastic | Semi Bellows | -40 °C | 105 ░C | Single | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 12 | Card Guides | ||
 EDAC Inc. | Non Specified - Dual Edge | Through Hole Right Angle | 12 | 0.156 in | 3.96 mm | 2 | 1 | Black | Tin | Female | Solder | Copper Alloy | Polyester Thermoplastic | Semi Bellows | -40 °C | 105 ░C | Dual | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 24 |
