146251 Series

Catalog

CONN HEADER VERT 80POS 2.54MM

Part	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Insulation Height [z]	Insulation Height [z]	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Material Flammability Rating	Style	Contact Shape	Contact Length - Post	Contact Length - Post	Connector Type	Contact Length - Mating	Contact Length - Mating	Overall Contact Length	Overall Contact Length	Contact Type	Mounting Type	Termination	Pitch - Mating	Pitch - Mating	Shrouding	Number of Positions	Current Rating (Amps)	Number of Positions Loaded	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Fastening Type	Contact Finish - Post	Operating Temperature [Max]	Operating Temperature [Min]	Insulation Color	Contact Finish - Mating	Insulation Material	Contact Material	Number of Rows [custom]
TE Connectivity AMP Connectors 9-146251-0	2.54 µm	100 µin	0.09 in	2.29 mm	5 µin	0.127 µm	UL94 V-0	Board to Board Cable	Square	0.125 in	3.18 mm	Header Breakaway	8.08 mm	0.318 in	13.55 mm	0.533 in	Male Pin	Through Hole	Solder	0.1 "	2.54 mm	Unshrouded	80	3 A	All	0.1 in	2.54 mm	Push-Pull	Tin	105 ░C	-65 ░C	Black	Gold	Liquid Crystal Polymer (LCP)	Copper Alloy	2
