29105 Series
Manufacturer: Phoenix Contact
Beta
⌘K
PLC-RSC- 48DC/21-21AU/MS
| Part | Coil Resistance | Operating Temperature [Min] | Operating Temperature [Max] | Operate Time | Approval Agency | Contact Form | Termination Style | Coil Current | Contact Rating (Current) | Coil Type | Must Operate Voltage | Features | Switching Voltage | Coil Voltage | Contact Material | Relay Type | Release Time | Mounting Type | Coil Voltage | Coil Voltage | Coil Voltage | Switching Voltage [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Phoenix Contact | 2.526 kOhms | -20 ░C | 60 °C | 6 ms | CE UKCA | DPDT (2 Form C) | Screw Terminal | 19 mA | 6 A | Non Latching | 40.3 VDC | Diode Socket Included | 250 VAC 250 VDC | 48 VDC | Silver Nickel (AgNi) | General Purpose | 10 ms | DIN Rail | ||||
 Phoenix Contact | 46 kOhms | -20 ░C | 50 °C | 6 ms | CE UKCA | DPDT (2 Form C) | Screw Terminal | 5 mA | 6 A | Non Latching | 207 VAC | Diode Lighted Indicator Socket Included Test Button | 250 VAC 250 VDC | Silver Nickel (AgNi) | General Purpose | 10 ms | DIN Rail | 230 VDC | 230 VAC | |||
 Phoenix Contact | 1333 Ohms | -20 ░C | 60 °C | 15 ms | CE UKCA | DPDT (2 Form C) | Spring Terminal | 18 mA | 6 A | Non Latching | Diode Lighted Indicator Mechanical Indicator Socket Included Test Button | 250 VAC 250 VDC | 24 VAC | Gold (Au) Silver Nickel (AgNi) | General Purpose | 15 ms | DIN Rail | |||||
 Phoenix Contact | 24 kOhms | -40 C | 55 °C | 6 ms | CE UKCA | SPDT (1 Form C) | Spring Terminal | 5 mA | 10 A | Non Latching | 96 VAC | Diode Lighted Indicator Socket Included Test Button | 250 VAC 250 VDC | Silver Nickel (AgNi) | General Purpose | 8 ms | DIN Rail | 120VAC/DC | ||||
 Phoenix Contact | 1333 Ohms | -20 ░C | 60 °C | 10 ms | cULus DNV EAC UL | DPDT (2 Form C) | Screw Terminal | 18 mA | 50 mA | Non Latching | Diode Lighted Indicator Socket Included | 24 VDC | Gold (Au) Silver Nickel (AgNi) | General Purpose | 10 ms | DIN Rail | 30 VAC 36 VDC | |||||
 Phoenix Contact | 1333 Ohms | -40 C | 60 °C | 15 ms | CE UKCA | SPDT (1 Form C) | Spring Terminal | 18 mA | 10 A | Non Latching | Diode Lighted Indicator Socket Included Test Button | 250 VAC 250 VDC | 24 VAC | Silver Nickel (AgNi) | General Purpose | 15 ms | DIN Rail | |||||
 Phoenix Contact | 1333 Ohms | -40 C | 60 °C | 15 ms | CE UKCA | SPDT (1 Form C) | Screw Terminal | 18 mA | 10 A | Non Latching | Lighted Indicator Socket Included | 250 VAC 250 VDC | 24 VAC | Silver Nickel (AgNi) | General Purpose | 15 ms | DIN Rail | |||||
 Phoenix Contact | 46 kOhms | -20 ░C | 50 °C | 15 ms | cULus DNV EAC UL | DPDT (2 Form C) | Screw Terminal | 5 mA | 50 mA | Non Latching | 207 VAC | Lighted Indicator Socket Included | Gold (Au) Silver Nickel (AgNi) | General Purpose | 15 ms | DIN Rail | 230 VDC | 230 VAC | 30 VAC 36 VDC | |||
 Phoenix Contact | 46 kOhms | -40 C | 50 °C | 6 ms | CE UKCA | SPDT (1 Form C) | Screw Terminal | 5 mA | 10 A | Non Latching | 207 VAC | Diode Lighted Indicator Socket Included Test Button | 250 VAC 250 VDC | Silver Nickel (AgNi) | General Purpose | 8 ms | DIN Rail | 230 VDC | 230 VAC | |||
 Phoenix Contact | 24 kOhms | -20 ░C | 55 °C | 15 ms | cULus DNV EAC UL | DPDT (2 Form C) | Screw Terminal | 5 mA | 50 mA | Non Latching | 96 VAC | Lighted Indicator Socket Included | Gold (Au) Silver Nickel (AgNi) | General Purpose | 15 ms | DIN Rail | 120VAC/DC | 30 VAC 36 VDC |
