PFSM.030 Series
Manufacturer: SCHURTER Inc.
Beta
⌘K
PFSM, IHOLD 0.3 A, 60.0 VDC, RESETTABLE FUSE, PCB ROHS COMPLIANT: YES
| Part | Approval Agency | Package / Case | Voltage - Max [Max] | Operating Temperature [Max] | Operating Temperature [Min] | Resistance - Post Trip (R1) (Max) [Max] | Current - Hold (Ih) (Max) [Max] | Time to Trip | Resistance - Initial (Ri) (Min) [Min] | Mounting Type | Qualification | Grade | Current - Trip (It) | Thickness (Max) [Max] | Thickness (Max) [Max] | Current - Max [Max] | Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 SCHURTER Inc. | cURus TUV | 2-SMD | 60 V | 85 °C | -40 C | 4.8 Ohms | 300 mA | 3 s | 900 mOhms | Surface Mount | AEC-Q200 | Automotive | 600 mA | 0.125 in | 3.18 mm | 40 A | Polymeric |
