11_QMA-50 Series
Manufacturer: Huber+Suhner, Inc.
Beta
⌘K
11_QMA-50-3-1/133_NH
| Part | Body Finish | Operating Temperature [Max] | Operating Temperature [Min] | Voltage Rating | Center Contact Plating | Body Material | Dielectric Material | Fastening Type | Contact Termination | Center Contact Material | Mounting Type | Connector Type | Housing Color | Frequency - Max [Max] | Impedance | Number of Ports | Shield Termination | Cable Group |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Huber+Suhner, Inc. | White Bronze | 85 °C | -40 C | 480 V | Gold | Brass | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Push-Pull | Crimp | Brass | Free Hanging (In-Line) | Plug Male Pin | Silver | 18 GHz | 50 Ohms | 1 | Solder | |
 Huber+Suhner, Inc. | White Bronze | 85 °C | -40 C | 480 V | Gold | Bronze | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Push-Pull | Crimp | Brass | Free Hanging (In-Line) | Plug Male Pin | Silver | 18 GHz | 50 Ohms | 1 | Crimp | RD-316 |
 Huber+Suhner, Inc. | White Bronze | 85 °C | -40 C | 480 V | Gold | Bronze | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Push-Pull | Crimp | Beryllium Copper Bronze | Free Hanging (In-Line) | Plug Male Pin | Silver | 18 GHz | 50 Ohms | 1 | Solder | RG-141 |
 Huber+Suhner, Inc. | White Bronze | 85 °C | -40 C | 480 V | Gold | Bronze | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Push-Pull | Solder | Brass | Free Hanging (In-Line) | Plug Male Pin | Silver | 18 GHz | 50 Ohms | 1 | Crimp | 223 400 RG-142 |
 Huber+Suhner, Inc. | White Bronze | 85 °C | -40 C | 480 V | Gold | Brass | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Push-Pull | Crimp | Bronze | Free Hanging (In-Line) | Plug Male Pin | Silver | 18 GHz | 50 Ohms | 1 | Crimp | LMR-240 |
 Huber+Suhner, Inc. | White Bronze | 85 °C | -40 C | 480 V | Gold | Brass | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Push-Pull | Crimp | Bronze | Free Hanging (In-Line) | Plug Male Pin | Silver | 18 GHz | 50 Ohms | 1 | Crimp | LMR-240 |
Huber+Suhner, Inc. | White Bronze | 85 °C | -40 C | 480 V | Gold | Bronze | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Push-Pull | Solder | Brass | Free Hanging (In-Line) | Plug Male Pin | Silver | 18 GHz | 50 Ohms | 1 | Crimp | RG-58 |
 Huber+Suhner, Inc. | White Bronze | 85 °C | -40 C | 480 V | Gold | Bronze | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Push-Pull | Solder | Brass | Free Hanging (In-Line) | Plug Male Pin | Silver | 18 GHz | 50 Ohms | 1 | Crimp | RG-58 |
Huber+Suhner, Inc. | White Bronze | 85 °C | -40 C | 480 V | Gold | Bronze | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Push-Pull | Crimp | Beryllium Copper Bronze | Free Hanging (In-Line) | Plug Male Pin | Silver | 18 GHz | 50 Ohms | 1 | Solder | RG-141 |
 Huber+Suhner, Inc. | White Bronze | 85 °C | -40 C | 480 V | Gold | Bronze | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Push-Pull | Crimp | Brass | Free Hanging (In-Line) | Plug Male Pin | Silver | 18 GHz | 50 Ohms | 1 | Crimp | RD-316 |
