857-036 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 36POS 0.156
| Part | Material - Insulation | Termination Rows [custom] | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Number of Rows [custom] | Contact Finish Thickness | Contact Finish Thickness | Color | Termination | Card Type | Contact Type | Contact Material | Operating Temperature [Max] | Operating Temperature [Min] | Number of Positions | Contact Finish | Pitch | Pitch | Number of Positions/Bay/Row [custom] | Card Thickness [Max] | Card Thickness [Min] | Mounting Type | Gender | Read Out | Termination Rows | Number of Positions/Bay/Row | Features | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | 2 | 0.25 Ám | 10 Áin | Black | Solder | Non Specified - Dual Edge | Semi Bellows | Copper Alloy | 125 °C | -40 C | 36 | Gold | 3.96 mm | 0.156 in | 18 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Female | Dual | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | Flush Mount M3 Threaded Insert Top Opening | 2 | Black | Solder | Non Specified - Dual Edge | Semi Bellows | Copper Alloy | 125 °C | -40 C | 36 | Tin | 3.96 mm | 0.156 in | 18 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Female | Dual | ||||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | 4-40 Flush Mount Threaded Insert Top Opening | 2 | 0.25 Ám | 10 Áin | Black | Solder | Non Specified - Dual Edge | Semi Bellows | Copper Alloy | 125 °C | -40 C | 36 | Gold | 3.96 mm | 0.156 in | 18 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | Female | Single | ||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | 2 | Black | Solder | Non Specified - Dual Edge | Semi Bellows | Copper Alloy | 125 °C | -40 C | 72 | Tin | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | Female | Dual | 1 | 36 | ||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | 0.128 " | Side Mount Opening Unthreaded | 3.25 mm | 2 | 0.25 Ám | 10 Áin | Black | Solder | Non Specified - Dual Edge | Semi Bellows | Copper Alloy | 125 °C | -40 C | 36 | Gold | 3.96 mm | 0.156 in | 18 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Board Edge Straddle Mount | Female | Dual | Card Extender | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Flush Mount M3 Threaded Insert Top Opening | 2 | 0.25 Ám | 10 Áin | Black | Wire Wrap | Non Specified - Dual Edge | Semi Bellows | Copper Alloy | 125 °C | -40 C | 72 | Gold | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Female | Dual | 1 | 36 | ||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 0.156 " | Flush Mount Top Opening Unthreaded | 3.96 mm | 2 | Black | Solder | Non Specified - Dual Edge | Semi Bellows | Copper Alloy | 125 °C | -40 C | 72 | Tin | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | Female | Dual | 1 | 36 | ||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 4-40 Flush Mount Threaded Insert Top Opening | 0.25 Ám | 10 Áin | Black | Solder | Non Specified - Single Edge | Semi Bellows | Copper Alloy | 125 °C | -40 C | 36 | Gold | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | Female | Single | 1 | 36 | 1 | ||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | 0.128 " | Side Mount Opening Unthreaded | 3.25 mm | 2 | 0.25 Ám | 10 Áin | Black | Solder | Non Specified - Dual Edge | Semi Bellows | Copper Alloy | 125 °C | -40 C | 36 | Gold | 3.96 mm | 0.156 in | 18 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Female | Dual | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 0.25 Ám | 10 Áin | Black | Solder | Non Specified - Single Edge | Semi Bellows | Copper Alloy | 125 °C | -40 C | 36 | Gold | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Female | Single | 1 | 36 | 1 |
