19S201 Series
Manufacturer: Rosenberger
Beta
⌘K
SMP RIGHT ANGLE PLUG PCB
| Part | Voltage Rating | Dielectric Material | Body Finish | Body Material | Center Contact Plating | Operating Temperature [Max] | Operating Temperature [Min] | Mating Cycles | Frequency - Max [Max] | Center Contact Material | Fastening Type | Shield Termination | Impedance | Number of Ports | Contact Termination | Mounting Type | Housing Color | Connector Type | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Rosenberger | 335 V | Polytetrafluoroethylene (PTFE) | Gold | Brass | Gold | 155 C | -65 ░C | 500 | 26.5 GHz | Brass | Snap-On | Solder | 50 Ohms | 1 | Solder | Right Angle Surface Mount | Gold | Plug Male Pin | |
 Rosenberger | 335 V | Liquid Crystal Polymer (LCP) | Gold | Bronze | Gold | 155 C | -65 ░C | 500 | 26.5 GHz | Bronze | Snap-On | Solder | 50 Ohms | 1 | Solder | Right Angle Surface Mount | Gold | Plug Male Pin | |
 Rosenberger | 335 V | Liquid Crystal Polymer (LCP) | Gold | Brass | Gold | 155 C | -65 ░C | 500 | 26.5 GHz | Brass | Snap-On | Solder | 50 Ohms | 1 | Solder | Right Angle Surface Mount | Gold | Plug Male Pin | Hermedically Sealed Limited Detent |
