BLC2425 Series

Catalog

RF MOSFET LDMOS 32V SOT1250-1

Part	Voltage - Rated	Supplier Device Package	Voltage - Test	Configuration	Package / Case	Mounting Type	Power - Output	Gain	Frequency	Current - Test	Frequency [Min]	Frequency [Max]	Current Rating (Amps)
Ampleon USA Inc. BLC2425M8LS300PZ	65 V	SOT1250-1	32 V	Common Source Dual	SOT1250-1	Surface Mount	300 W	17.5 dBi	2.45 GHz	20 mA
Ampleon USA Inc. BLC2425M10LS500PY	65 V	SOT1250-1	32 V	2 N-Channel (Dual) Common Source	SOT1250-1	Surface Mount	500 W	14.5 dBi		20 mA	2.4 GHz	2.5 GHz	4.2 µA
Ampleon USA Inc. BLC2425M9LS250Z	65 V	SOT-1270-1	32 V		SOT-1270-1	Surface Mount	250 W	18.5 dBi	2.45 GHz	20 mA
Ampleon USA Inc. BLC2425M10LS250Y	65 V	SOT-1270-1	32 V	N-Channel	SOT-1270-1	Surface Mount	250 W	14.4 dBd		100 mA	2.4 GHz	2.5 GHz	2.8 µA
Ampleon USA Inc. BLC2425M10LS250Z	65 V	SOT-1270-1	32 V		SOT-1270-1	Surface Mount	250 W	14.4 dBd		100 mA	2.4 GHz	2.5 GHz	2.8 µA
Ampleon USA Inc. BLC2425M8LS300PY	65 V	SOT1250-1	32 V	Common Source Dual	SOT1250-1	Surface Mount	300 W	17.5 dBi	2.45 GHz	20 mA
