PH2 Series
Manufacturer: Adam Tech
Beta
⌘K
HEADERS & WIRE HOUSINGS CONN SPRING MOD FEMALE 6POS PCB
| Part | Pitch | Pitch | Number of Contacts | Row Spacing | Row Spacing | Number of Rows [custom] | Mounting Type | Connector Type | Contact Shape | Termination | Current Rating (Amps) | Insulation Material | Voltage Rating | Contact Length - Post | Contact Length - Post | Number of Positions Loaded | Contact Finish Thickness - Mating | Contact Type | Operating Temperature [Min] | Operating Temperature [Max] | Contact Finish - Mating | Contact Length - Mating | Contact Length - Mating | Insulation Color | Pitch - Mating | Pitch - Mating | Shrouding | Overall Contact Length | Overall Contact Length | Row Spacing - Mating [x] | Row Spacing - Mating [x] | Material Flammability Rating | Insulation Height | Insulation Height | Contact Finish - Post | Contact Material | Fastening Type | Number of Positions | Contact Finish Thickness - Post | Contact Finish | Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Adam Tech | 0.1 " | 2.54 mm | 6 | 2.54 mm | 0.1 " | 2 | Through Hole | Compression Contact Female | |||||||||||||||||||||||||||||||||
 Adam Tech | 2 | Through Hole | Header | Square | Solder | 3 A | Polybutylene Terephthalate (PBT) Glass Filled | 250 VAC | 3.05 mm | 0.12 in | All | Flash | Male Pin | -55 C | 105 ░C | Gold | 5.97 mm | 0.235 in | Black | 0.1 " | 2.54 mm | Unshrouded | 0.453 in | 11.5 mm | 0.1 in | 2.54 mm | UL94 V-0 | 0.098 " | 2.5 mm | Gold | Brass | Push-Pull | 12 | ||||||||
 Adam Tech | 2 | Through Hole | Header | Square | Solder | 3 A | Polybutylene Terephthalate (PBT) Glass Filled | 250 VAC | 3.05 mm | 0.12 in | All | Flash | Male Pin | -55 C | 105 ░C | Gold | 5.97 mm | 0.235 in | Black | 0.1 " | 2.54 mm | Unshrouded | 0.453 in | 11.5 mm | 0.1 in | 2.54 mm | UL94 V-0 | 0.098 " | 2.5 mm | Gold | Brass | Push-Pull | 16 | Flash | |||||||
 Adam Tech | 0.1 " | 2.54 mm | 8 | 2.54 mm | 0.1 " | 2 | Surface Mount | Piston | Gold | Brass | |||||||||||||||||||||||||||||||
 Adam Tech | 0.1 " | 2.54 mm | 8 | 2.54 mm | 0.1 " | 2 | Solder Cup Through Hole | Piston | Gold | Brass | |||||||||||||||||||||||||||||||
 Adam Tech | 2 | Through Hole | Header | Square | Solder | 3 A | Polybutylene Terephthalate (PBT) Glass Filled | 250 VAC | 3.05 mm | 0.12 in | All | Flash | Male Pin | -55 C | 105 ░C | Gold | 5.97 mm | 0.235 in | Black | 0.1 " | 2.54 mm | Unshrouded | 0.453 in | 11.5 mm | 0.1 in | 2.54 mm | UL94 V-0 | 0.098 " | 2.5 mm | Gold | Brass | Push-Pull | 6 | Flash | |||||||
 Adam Tech | 2 | Through Hole | Header | Square | Solder | 3 A | Polybutylene Terephthalate (PBT) Glass Filled | 250 VAC | 3.05 mm | 0.12 in | All | Flash | Male Pin | -55 C | 105 ░C | Gold | 5.97 mm | 0.235 in | Black | 0.1 " | 2.54 mm | Unshrouded | 0.453 in | 11.5 mm | 0.1 in | 2.54 mm | UL94 V-0 | 0.098 " | 2.5 mm | Gold | Brass | Push-Pull | 4 | Flash |
