8307 Series
Manufacturer: Belden Inc.
Beta
⌘K
MULTI-PAIR 14COND 22AWG
| Part | Shield Coverage | Shield Material | Usage | Conductor Material | Number of Conductors | Conductor Insulation | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Conductor Strand [custom] | Conductor Strand [custom] | Ratings | Wire Gauge | Operating Temperature [Max] | Operating Temperature [Min] | Jacket (Insulation) Material | Cable Type | Shield Type | Length | Length | Voltage | Jacket Color | Jacket (Insulation) Diameter | Jacket (Insulation) Diameter | Length [x] | Length [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | 65 % 100 % | Aluminum Copper Tinned | Computer | Copper Tinned | 14 | Poly-Vinyl Chloride (PVC) | 0.035 in | 0.889 mm | 30 AWG | 7 | UL Style 2464 | 22 AWG | 80 °C | -30 ░C | Poly-Vinyl Chloride (PVC) | Multi-Pair | Braid Foil | 304.8 m | 1000 ft | 300 VDC | Chrome | 8.84 mm | 0.348 in | ||
Belden Inc. | 65 % 100 % | Aluminum Copper Tinned | Computer | Copper Tinned | 14 | Poly-Vinyl Chloride (PVC) | 0.035 in | 0.889 mm | 30 AWG | 7 | UL Style 2464 | 22 AWG | 80 °C | -30 ░C | Poly-Vinyl Chloride (PVC) | Multi-Pair | Braid Foil | 152.4 m | 500 ft | 300 VDC | Chrome | 8.84 mm | 0.348 in | ||
 Belden Inc. | 65 % 100 % | Aluminum Copper Tinned | Computer | Copper Tinned | 14 | Poly-Vinyl Chloride (PVC) | 0.035 in | 0.889 mm | 30 AWG | 7 | UL Style 2464 | 22 AWG | 80 °C | -30 ░C | Poly-Vinyl Chloride (PVC) | Multi-Pair | Braid Foil | Chrome | 8.84 mm | 0.348 in | 100 ft | 30.5 m |
